LEGRAND 020652 020652 LEGRAND XL3 RAIL ADJUSTABLE L850 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

020652 LEGRAND XL3 RAIL ADJUSTABLE L850

020652

020652

LEGRAND

1 Pcs.

XL3 RAIL ADJUSTABLE L850 Universal adjustable fixing device XL³ 800/4000 - 36 modules Changeoverswitches, T3, 32 A, rear mounting, 4 contact unit(s), Contacts: 8, 60 °, maintained, With 0 (Off) position, 2-0-1, Design number 88

Automation > Mounting rail
XL3 800-4000 ENERGY DISTRIBUTION CABINETS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed as a Legrand XL3 RAIL ADJUSTABLE L850, this adjustable rail supports the internal mechanical layout of modular distribution boards and industrial control enclosures. Adjustable framework components allow panel builders to customize depth and spacing for complex switchgear assemblies. Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Height (EF000040): 35 mm
  • Model (EF000010): DIN rail (top hat rail) 15 mm
  • Material thickness (EF000386): 15 mm
  • Material (EF002169): Steel
  • Punch shape (EF001457): Long-slot
  • Length (EF001438): 850 mm

More info

▲
  • Pack (number of units)1
  • Volume (dm3)5.398
  • Weight (g)1 175.00
Product characteristics
Adjustable universal fixing devices
  • Comprising a rail and 2 adjustable fixing brackets
  • Fit onto the functional uprights
  • For 36 module cabinets and enclosures
General characteristics
Solid faceplates and accessories for XL³ 4000
