View larger
Images are for illustrative purposes only. Please refer to data sheet for details
020205 LEGRAND XL3 PLATE MOUNTING DPX-IS 250
020205
020205
LEGRAND
1 Pcs.
XL3 PLATE MOUNTING DPX-IS 250
Mounting plate fixed XL3 400 - for 1 DPX-IS 250 - vertical
XL³ 400 Fixed Mounting Plate for 1 DPX-IS 250 - Vertical
Automation > Mounting plate for distribution board
XL3 160-400 ENERGY DISTRIBUTION CABINETS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Product features
Plates for equipment fixed version above connection - fixing in the studs functional vertical Mounting - If mounting is performed in the upper part of the cabinet to use a compulsory cover cubrebornas of 300 mm - Plate for mounting DPX-IS 250 - If the mounting is at the top of the cabinet to use a compulsory cover cubrebornas of 300 mmGeneral characteristics
XL3 400 equipment - for mounting DPX3 160, DPX3 250 and DPX-IS 250 mounting plate| Feature Name | Feature Value |
|---|---|
| Height (EF000040) | 600 mm |
| Material (EF002169) | Steel |
| Perforated (EF000115) | Yes |
| Surface protection (EF000139) | Untreated |
| Width (EF000008) | 515 mm |
