LEGRAND 020053 020053 LEGRAND XL3 160 SUPER. AISL. 3 ROWS View larger
Images are for illustrative purposes only. Please refer to data sheet for details

020053 LEGRAND XL3 160 SUPER. AISL. 3 ROWS

020053

020053

LEGRAND

1 Pcs.

XL3 160 SUPER. AISL. 3 ROWS Box distribution insulating XL3 160 - fully modular - 3 rows of 24 modules Reversing switches, T3, 32 A, rear mounting, 4 contact unit(s), Contacts: 7, 45 °, maintained, With 0 (Off) position, 2-0-1, Design number 131

Automation > Small distribution board
XL3 160-400 ENERGY DISTRIBUTION CABINETS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Legrand 020053 xl3 160 super. aisl. 3 rows is a surface-mounted insulating distribution enclosure built to house modular control components and safeguard operators from live parts. Insulated electrical cabinets provide reliable protection classes for commercial power distribution and sub-circuit management.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height (EF000040): 600 mm
  • Inner depth (EF001131): 115 mm
  • Transparent cover/door (EF006244): No
  • Degree of protection (IP) (EF005474): IP43
  • DIN-rail (EF001134): Yes
  • Housing material (EF001596): Plastic
  • With lock (EF006306): Yes
  • Mounting method (EF000003): Surface mounted
  • Number of rows (EF000266): 3
  • Cover model (EF009212): With notch
  • RAL-number (EF000116): 7035
  • Built-in depth (EF000218): 170 mm
  • Type of covering (EF000339): Door
  • With mounting plate (EF000118): No
  • Extension possible (EF001088): Yes
  • Width in number of modular spacings (EF002950): 24

More info

▲

Product features

Distribution box modular insulation, surface - Boxes to create montages of class II (or totally isolated) according to IEC 61439-1/3 - IP 43 - IK 07 with seal and door IP 40 - IK 07 with door IP 30 - IK 04 without door - Bracelets guide to wiring vertical - Support DPX3 160 - N. º of rows: 3 - N. º of modules: 72 - Height: 600 mm Width: 575 mm Depth: 147 mm

General characteristics

Cabinets installation on surface XL3 160 - distribution boxes with "ready to use" - Chassis removable equipped with profiles that are symmetrical - brass Bar for drivers of protection: 36 holes 1.5 to 10 mm? and holes, 2 x 35 mm? - Capacity of 24 modules per row - RAL 7035 - Are supplied complete with profiles and front panels. The doors are ordered separately - For creating assemblies certified IN accordance with IEC en 61439-1 - removable side Panels - top and bottom Panels removable and separable to insert plate cable gland adjustable
