LEGRAND 004842 004842 LEGRAND TERMINAL REPART. 8P IP2 NEUTRAL View larger
Images are for illustrative purposes only. Please refer to data sheet for details

004842 LEGRAND TERMINAL REPART. 8P IP2 NEUTRAL

004842

004842

LEGRAND

10 Pcs.

TERMINAL REPART. 8P IP2 NEUTRAL Legrand Fully Shrouded IP2X Neutral Terminal Block Rail Mounting 0 Entry 8 Exit 75mm Blue IP2X distribution terminal - neutral - 8 connection. from 1.5 to 16mm² - Blue - L. 75mm

Automation > Rail terminal bar
SPLITTERS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Legrand neutral terminal block creates an organized neutral busbar connection on DIN rails, allowing multiple branch circuits to terminate safely in a distribution board.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 30 mm
  • Nominal current: 76 A
  • Connection type: Screwing
  • Mounting method: DIN rail
  • Contact safe: Yes
  • Suitable for extra fine-strand conductors: No
  • Number of poles: 1
  • Conductor cross section, output: 1.5 mm²
  • Suitable for stranded conductors: Yes
  • Depth: 16 mm
  • Conductor cross section, input: 1.5 mm²
  • Suitable for fine strand conductors: Yes
  • Width: 75 mm
  • Suitable for solid conductors: Yes
  • Number of outputs: 7
  • Number of inputs: 1

More info

▲
Number of poles1
Nominal current76 A
Connection typeScrewing
Mounting methodDIN rail
Number of inputs1
Number of outputs7
Suitable for solid conductorsYes
Suitable for stranded conductorsYes
Suitable for fine strand conductorsYes
Suitable for fine strand conductors without cable end sleeveNo
Suitable for extra fine-strand conductorsNo
Suitable for extra fine-strand conductors without cable end sleeveNo
Conductor cross section, input1.5-16 mm²
Conductor cross section, output1.5-16 mm²
Contact safeYes
Height30 mm
Width75 mm
Depth16 mm
Degree of protection (IP)IP2X
Operating / setting temperature-5-40 °C
Storage temperature-25-70 °C
Type of distribution blocksNeutral
Terminals capacity1.5-16 mm²
Label space/information surfaceNo
