85001628 LAPP Single core cart S12
85001628
85001628
LAPP
1 unit
Automation > Automation and operation
Automation and operation
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A Lapp 85001628 LAPP Single core cart S12 acts as a dedicated workshop trolley built to organize and dispense multiple wire coils sequentially. Operators use these compact mobile racks to keep electrical components accessible and tangle-free near production benches. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Outer diameter cable: max. 10 mm Coil Diameter: max. 295 mm Inner diameter: 80-180 mm Heigth: max. 80 mm
- Maximum load per TRONIC: 7 kg
- Max load of the TRONIC S12 trolley: 1st level: 60 kg 2nd level: 40 kg 3rd level: 30 kg
More info
▲Mobile and flexible solutions for transporting, storing and unwinding rolls and coils of unipolar cables.
TRONIC products are perfectly adapted for ROLLS of LAPP H05V-K and H07V-K unipolar cables (S-finished references for higher density), as well as all other LAPP unipolar cables.
proceeds
- Facilitates handling and storage of rolls and coils of unipolar cables and ensures a clean and organized workplace
- Direct extraction of various products on the job site ensures fast and efficient assembly processes
- Easy-to-use solution with very short preparation times thanks to ease of recharging
- Unipolar cables can be unrolled with horizontal extraction without twisting/folding
- The application of barcodes allows the use of Kanban solutions. With FLEXIMARK® other types of codes can also be used.
Scope of use
- Transport, store and unwind unipolar cables
- The "climber" variant allows you to climb/descend stairs and overcome other barriers
- Mobile storage and uninveloped solutions for the workplace.
Product features
- The TRONIC module consists of 2 TRONIC boxes mounted on a stand
- TRONIC S12 trolley for unipolar cables:
capacity for 12-18 coils of unipolar cables (depending on coil width)
trolley frame with tool holder - Cart for TRONIC Modules for unipolar cables, climber and with optional compartment for tools (reference: 85001640)
Dimensions
- Fits for cable rings:
- Outer diameter cable: max. 10 mm
Coil Diameter: max. 295 mm
Inner diameter: 80-180 mm
Heigth: max. 80 mm
General data
- Maximum load per TRONIC: 7 kg
- Max load of the TRONIC S12 trolley:
1st level: 60 kg
2nd level: 40 kg
3rd level: 30 kg
Material
- Painted steel
