LAPP 61804214 61804214 FIPLOCK M16x1,5 / 12 BK LAPP FIPLOCK ONE M16X1,5 / 12 BK View larger
Images are for illustrative purposes only. Please refer to data sheet for details

61804214 FIPLOCK M16x1,5 / 12 BK LAPP FIPLOCK ONE M16X1,5 / 12 BK

61804214

61804214

FIPLOCK M16x1,5 / 12 BK

LAPP

10 Pcs.

FIPLOCK ONE M16X1,5 / 12 BK FIPLOCK

Automation > Screw connection for corrugated plastic hose
SILVYN cabling

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for secure mechanical retention, the Lapp 61804214 threaded connection for corrugated polyamide tube locks flexible conduits into position on control panels. These threaded components protect wiring harnesses from strain in harsh industrial conditions. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Description of class ETIM 5.0: threaded connection for corrugated polyamide tube
  • ETIM 5.0 Class ID: EC001176
  • ETIM 6.0 Class-ID: EC001176
  • ETIM 6.0 Class-Description: threaded connection for flexible corrugated plastic tube

More info

▲

FIPLOCK®ONE M

New fitting system with innovative locking system

proceeds

  • Very high tensile strength thanks to the total denting system
  • Ensures mounting safety thanks to the integrated coding system
  • Excellent IP grade
  • Cost savings through quick and easy installation

Scope of use

  • Suitable for FIPLOCK®PA6/PA12
  • Increased tightness demand
  • For indoor and outdoor use

Product features

  • Total locking system thanks to 360° dentate system
  • Locking mechanism with integrated coding system
  • Extended sealing range along multiple corrugated tube waves

ETS Classification 5

  • ETIM 5.0 Class ID: EC001176
  • Description of class ETIM 5.0: threaded connection for corrugated polyamide tube

ETTIM Rating 6

  • ETIM 6.0 Class-ID: EC001176
  • ETIM 6.0 Class-Description: threaded connection for flexible corrugated plastic tube

Certifications

  • IEC EN 61386-23
  • IN 45545-2 HL3

Available colors

  • Grey (RAL 7005)
    Black (RAL 9005), UV resistant

Material

  • PA 6
    Halogen-free
  • Fire performance according to UL 94 V0

Degree of protection:

  • IP66/IP67/IP68/IP69

Temperature range

  • -45°C to +120°C

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
