LAPP 61742426 61742426 PROTECT BOX 3.2/1.6 BK LAPP Shrink tube PROTECT Box 3.2/1.6 BK View larger
Images are for illustrative purposes only. Please refer to data sheet for details

61742426 PROTECT BOX 3.2/1.6 BK LAPP Shrink tube PROTECT Box 3.2/1.6 BK

61742426

61742426

PROTECT BOX 3.2/1.6 BK

LAPP

1 Pcs.

Shrink tube PROTECT Box 3.2/1.6 BK Shrink tube PROTECT Box

Automation > Shrink tubing
Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Supplied in a convenient dispenser format, this Lapp 61742426 heat-shrink tubing delivers reliable electrical insulation for everyday wiring tasks. Maintenance crews utilize heat-shrink materials to repair damaged insulation and bundle conductors neatly inside enclosures. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Green-yellow shrink tube: For identifying and marking earthing connectors and cables
  • Flame-retardant (except colour: clear): Yes
  • UV-resistant (only colour: black): Yes
  • UL 224 approval (except colour: transparent): Yes
  • UL file no.: E476215 (except colour: transparent)
  • Dielectric strength: 20 kV/mm
  • Shrinking ratio: 2:1
  • Shrinking temperature: +90°C
  • ETIM 5.0 Class-ID: EC000217
  • ETIM 5.0 Class-Description: Heat-shrink tubing
  • ETIM 6.0 Class-ID: EC000217
  • ETIM 6.0 Class-Description: Shrink tubing

More info

▲

The shrinkable plastic conduit in an handy box is especially suitable for small-scale consumers.

Thin walled

Benefits

  • Flexible
  • Excellent physical and mechanical properties
  • Approved for the use in North America and Canada

Application range

  • Insulation, protection and cable bundling
  • Green-yellow shrink tube: For identifying and marking earthing connectors and cables

Product features

  • Flame-retardant (except colour: clear)
  • Silicone-free
  • UV-resistant (only colour: black)

Norm references / Approvals

  • UL 224 approval (except colour: transparent)
  • UL file no.: E476215 (except colour: transparent)

Note

  • Not resistant against engine oils

Included

  • Stackable boxes for easy storage

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000217
  • ETIM 5.0 Class-Description: Heat-shrink tubing

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000217
  • ETIM 6.0 Class-Description: Shrink tubing

On request

  • Other colours are available upon request

Note

  • Thin walled
  • Dielectric strength: 20 kV/mm

Info

  • Shrinking ratio: 2:1

Colour delivered

  • Black
    Transparent
    Green-yellow

Material

  • Cross-linked polyolefin

Temperature range

  • -55°C to +135°C
  • Shrinking temperature: +90°C

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
