LAPP 53112780 53112780 SKINTOP MS-IS-M 25x1,5 LAPP SKINTOP MS-IS-M 25x1,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

53112780 SKINTOP MS-IS-M 25x1,5 LAPP SKINTOP MS-IS-M 25x1,5

53112780

53112780

SKINTOP MS-IS-M 25x1,5

LAPP

25 Pcs.

SKINTOP MS-IS-M 25x1,5 SKINTOP® MS-IS-M

Cables > Cable gland
SKINTOP cabling

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Lapp part number 53112780 is a SKINTOP MS-IS-M 25x1,5 cable screw gland built for applications requiring reliable sealing and superior strain relief in automation infrastructure. It protects delicate conductors passing through metallic enclosures against mechanical abrasion and fluids. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Body: nickel-plated brass Insert: polyamide Sealing: CR O-ring: NBR
  • Dynamic: -25°C up to +100°C
  • Fixed: -40°C up to +100°C
  • ETIM 5.0 Class-ID: EC000441
  • ETIM 5.0 Class-Description: Cable screw gland
  • ETIM 6.0 Class-ID: EC000441
  • ETIM 6.0 Class-Description: Cable screw gland

More info

▲

SKINTOP® MS-IS-M, brass cable gland for industrial connectors with short connection thread for more space and variable clamping ranges

Benefits

  • Short connection thread for more space inside the industrial connectors
  • Wide, variable clamping ranges
  • Optimum strain relief

Application range

  • Specially designed for use on industrial connectors

Product Make-up

  • Metric connection thread acc. to DIN EN 60423
  • Basis for technical information DIN IEC 62444

Included

  • Rectangular connector is not included, just the cable gland

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000441
  • ETIM 5.0 Class-Description: Cable screw gland

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000441
  • ETIM 6.0 Class-Description: Cable screw gland

Caution

  • Refer to Appendix T21 for the installation dimensions and torques

Material

  • Body: nickel-plated brass
    Insert: polyamide
    Sealing: CR
    O-ring: NBR

Protection rating

  • IP 68 - 5 bar

Temperature range

  • Dynamic: -25°C up to +100°C
  • Fixed: -40°C up to +100°C
