EPIC H-B 16 DF EPIC® Docking frame

Connectors > Module carrier frame for industrial connectors
EPIC rectangular

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A contact insert holder for industrial connectors, like the Lapp 44429442 EPIC H-B 16 DF, serves as a resilient docking frame for automated and rack-mounted plug-in systems. It absorbs lateral and vertical variances during connection phases to protect high-density wiring setups. Please note that pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Scope of delivery per packaging unit: 2 frams with 8 screws
  • Pull-In range in x and y axis: + - 1,5mm
  • Docking frame: stainless steel Screws: steel zinc plated
  • ETIM 5.0 Class-ID: EC002312
  • ETIM 5.0 Class-Description: Contact insert holder for industrial connectors
  • ETIM 6.0 Class-ID: EC002312
  • ETIM 6.0 Class-Description: Contact insert holder for industrial connectors

More info

▲

The installation system for control cabinets is available as a set or as single components (upper part for the cable connector, lower part for installation to DIN rail).

  • Mounting system for control cabinets
  • for float-mounting fixing of the inserts

Application range

  • Control cabinet manufacturing
  • Wind power plants

Product features

  • Scope of delivery per packaging unit: 2 frams with 8 screws
  • Special screws adapted to frame
  • Pull-In range in x and y axis: + - 1,5mm

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC002312
  • ETIM 5.0 Class-Description: Contact insert holder for industrial connectors

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC002312
  • ETIM 6.0 Class-Description: Contact insert holder for industrial connectors

Material

  • Docking frame: stainless steel
    Screws: steel zinc plated

Cycle of mechanical operation

  • 500
