LAPP 21700126 21700126 LAPP ETHERLINE ACCESS M08T-2GEN View larger
Images are for illustrative purposes only. Please refer to data sheet for details

21700126 LAPP ETHERLINE ACCESS M08T-2GEN

21700126

21700126

LAPP

1 unit


Automation > Networks+Wireless active
Networks+Wireless active

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

This mains switch unit, designated as the Lapp 21700126 Etherline Access M08T-2Gen, functions as a core networking device designed to manage data traffic and supply reliable connectivity across industrial Ethernet infrastructures. Network switches of this type coordinate multi-port communications and support robust industrial communication protocols. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • RJ45 ports: 10/100/1000 BaseT(X)
  • Buffer packet size: 1 Mbit
  • Supported protocols: HTTPS/SSL, SSH, TACACS+, RADIUS, SNTP Client, Ethernet IP, Modbus TCP
  • Redundant voltage supply: 24 VDC
  • ETIM 5.0 Class-ID: EC000734
  • ETIM 5.0 Class-Description: mains switch
  • ETIM 6.0 Class-ID: EC000734
  • ETIM 6.0 Class-Description: mains switch

More info

▲

Industrial network switches for Ethernet-based solutions in Smart Factories.

  • Redundant voltage supply
  • Robust metal housing and DIN profile mount
  • No need for ventilation or maintenance

proceeds

  • Improve total operating costs with faster installation and shorter downtime
  • The most flexible solutions available globally from the same provider

Product features

  • Easy installation of redundant networks with a reconfiguration time of < 20 ms
  • RJ45 ports: 10/100/1000 BaseT(X)
  • Buffer packet size: 1 Mbit
  • Supported protocols: HTTPS/SSL, SSH, TACACS+, RADIUS, SNTP Client, Ethernet IP, Modbus TCP
  • Redundant voltage supply: 24 VDC

Reference Standards / Approvals

  • UL 61010
  • Shock IEC 60068-2-27
  • Free fall IEC60068-2-32
  • Vibration IEC 60068-2-6

ETS Classification 5

  • ETIM 5.0 Class-ID: EC000734
  • ETIM 5.0 Class-Description: mains switch

ETTIM Rating 6

  • ETIM 6.0 Class-ID: EC000734
  • ETIM 6.0 Class-Description: mains switch

Power supply

  • DC 24 V (18-30 V DC)

Degree of protection:

  • IP 40

Temperature range

  • -40°C to +75°C

Product Datasheet
