LAPP 21700124 21700124 LAPP ETHERLINE ACCESS U08T-2GEN View larger
Images are for illustrative purposes only. Please refer to data sheet for details

21700124 LAPP ETHERLINE ACCESS U08T-2GEN

21700124

21700124

LAPP

1 unit


Automation > Networks+Wireless active
Networks+Wireless active

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for streamlined industrial networking, the Lapp 21700124 Etherline Access U08T-2Gen functions as an Ethernet mains switch that links multiple field devices and control panels into a unified communication backbone. Network hardware of this classification maintains data packet prioritization and continuous uptime in automated operations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • RJ45 ports: 10/100 BaseT(X)
  • RJ45 ports: 10/100/1000 BaseT(X)
  • Buffer packet size: min. 1Mbit
  • Redundant voltage supply: 24 VDC
  • ETIM 5.0 Class-ID: EC000734
  • ETIM 5.0 Class-Description: mains switch
  • ETIM 6.0 Class-ID: EC000734
  • ETIM 6.0 Class-Description: mains switch

More info

▲

Industrial network switches for Ethernet-based solutions in Smart Factories.

  • Redundant voltage supply
  • Robust metal housing and DIN profile mount

proceeds

  • Improve total operating costs with faster installation and shorter downtime
  • The most flexible solutions available globally from the same provider

Product features

  • RJ45 ports: 10/100 BaseT(X)
  • RJ45 ports: 10/100/1000 BaseT(X)
  • Buffer packet size: min. 1Mbit
  • Broadcast storm protection
  • Redundant voltage supply: 24 VDC

Reference Standards / Approvals

  • UL 61010
  • Shock IEC 60068-2-27
  • Free fall IEC60068-2-32
  • Vibration IEC 60068-2-6

ETS Classification 5

  • ETIM 5.0 Class-ID: EC000734
  • ETIM 5.0 Class-Description: mains switch

ETTIM Rating 6

  • ETIM 6.0 Class-ID: EC000734
  • ETIM 6.0 Class-Description: mains switch

Power supply

  • DC 24 V (18-30 V DC)

Degree of protection:

  • IP 30

Temperature range

  • -10°C to +60°C
