LAPP 1600198 1600198 H07RN-F 1X120 LAPP H07RN-F 1X120 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1600198 H07RN-F 1X120 LAPP H07RN-F 1X120

1600198

1600198

H07RN-F 1X120

LAPP

1 m.

H07RN-F 1X120 H07RN-F

Cables > Circular connector, mounting (without cable)
Rubber cables

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Heavy-duty rubber-sheathed flexible cables like the Lapp 1600198 H07RN-F 1X120 supply reliable electrical power to demanding industrial settings and mobile machinery. Power cables of this classification withstand mechanical stress, moisture, and weather exposure in outdoor installations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • According to EN 50565-2: In dry, damp and wet rooms as well as for fixed installation e.g. on the plaster
  • Core insulation: rubber compound, type EI 4
  • Outer sheath: rubber compound, type EM2
  • Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
  • From 6 cores: black with white numbers
  • U0/U: 450/750 V
  • Fixed installation: -25°C up to +60°C
  • Occasionally moved: -25°C bis +60°C
  • ETIM 5.0 Class-ID: EC001578
  • ETIM 5.0 Class-Description: Flexible cable
  • ETIM 6.0 Class-ID: EC001578
  • ETIM 6.0 Class-Description: Flexible cable

More info

▲

H07RN-F, HAR, power and control cable, rubber, heavy, 450/750 V, industrial and agricultural use, class 5, -25°C to +60°C, oil-resistant, flame-retardant

  • Medium mechanical stress
  • Oil-resistant

Benefits

  • For mechanically more demanding applications
  • 1000 V AC at protected + static laying
  • Arrangements made of single-core, rubber-sheathed cables H07RN-F can be used for short circuit-proof and short-to-ground-proof installations in accordance with IEC 60364-5-52/ HD 60364-5-52/ VDE 0100 Part 520

Application range

  • Handheld and power supply devices according to EN 50565-2
  • Medium, mechanical stress
  • Industrial, agricultural use
  • According to EN 50565-2: In dry, damp and wet rooms as well as for fixed installation e.g. on the plaster

Product features

  • Flame-retardant according IEC 60332-1-2
  • Oil-resistant according to EN 60811-404

Norm references / Approvals

  • <HAR> H07RN-F cable type approval according to EN 50525-2-21

Product Make-up

  • Bare copper wire according to HAR
  • Core insulation: rubber compound, type EI 4
  • Outer sheath: rubber compound, type EM2

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC001578
  • ETIM 5.0 Class-Description: Flexible cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC001578
  • ETIM 6.0 Class-Description: Flexible cable

Core identification code

  • Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
  • From 6 cores: black with white numbers

Conductor stranding

  • Fine wire according to VDE 0295 Class 5/ IEC 60228 Class 5

Minimum bending radius

  • 4 to 8 x outer diameter (EN 50565-1)

Nominal voltage

  • U0/U: 450/750 V

Test voltage

  • 2500 V

Protective conductor

  • G = with GN-YE protective conductor
  • X = without protective conductor

Current rating

  • According to IEC 60364-5-52/ VDE 0298-4
  • EN 50565-1/ VDE 0298-565-1

Temperature range

  • Fixed installation: -25°C up to +60°C
  • Occasionally moved: -25°C bis +60°C

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
