1600121 H07RN-F 3G10 LAPP H07RN-F 3G10
1600121
1600121
H07RN-F 3G10
LAPP
1 m.
Cables > Power cable less 1 kV, for moving application
Rubber cables
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Lapp 1600121 H07RN-F 3G10 is a heavy-duty rubber-sheathed flexible cable engineered for high-capacity electrical power transmission. Robust rubber cables are standard in demanding outdoor environments, industrial plants, and mobile equipment connections. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- According to EN 50565-2: In dry, damp and wet rooms as well as for fixed installation e.g. on the plaster
- Core insulation: rubber compound, type EI 4
- Outer sheath: rubber compound, type EM2
- Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
- From 6 cores: black with white numbers
- U0/U: 450/750 V
- Fixed installation: -25°C up to +60°C
- Occasionally moved: -25°C bis +60°C
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
- ETIM 6.0 Class-ID: EC001578
- ETIM 6.0 Class-Description: Flexible cable
More info
▲H07RN-F, HAR, power and control cable, rubber, heavy, 450/750 V, industrial and agricultural use, class 5, -25°C to +60°C, oil-resistant, flame-retardant
- Medium mechanical stress
- Oil-resistant
Benefits
- For mechanically more demanding applications
- 1000 V AC at protected + static laying
- Arrangements made of single-core, rubber-sheathed cables H07RN-F can be used for short circuit-proof and short-to-ground-proof installations in accordance with IEC 60364-5-52/ HD 60364-5-52/ VDE 0100 Part 520
Application range
- Handheld and power supply devices according to EN 50565-2
- Medium, mechanical stress
- Industrial, agricultural use
- According to EN 50565-2: In dry, damp and wet rooms as well as for fixed installation e.g. on the plaster
Product features
- Flame-retardant according IEC 60332-1-2
- Oil-resistant according to EN 60811-404
Norm references / Approvals
- <HAR> H07RN-F cable type approval according to EN 50525-2-21
Product Make-up
- Bare copper wire according to HAR
- Core insulation: rubber compound, type EI 4
- Outer sheath: rubber compound, type EM2
Classification ETIM 5
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC001578
- ETIM 6.0 Class-Description: Flexible cable
Core identification code
- Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
- From 6 cores: black with white numbers
Conductor stranding
- Fine wire according to VDE 0295 Class 5/ IEC 60228 Class 5
Minimum bending radius
- 4 to 8 x outer diameter (EN 50565-1)
Nominal voltage
- U0/U: 450/750 V
Test voltage
- 2500 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Current rating
- According to IEC 60364-5-52/ VDE 0298-4
- EN 50565-1/ VDE 0298-565-1
Temperature range
- Fixed installation: -25°C up to +60°C
- Occasionally moved: -25°C bis +60°C
