10432500 H-Q 5 BC FEMALE INSERT LAPP H-Q 5 BC FEMALE INSERT
10432500
10432500
H-Q 5 BC FEMALE INSERT
LAPP
10 Pcs.
Connectors > Contact insert for rectangular connectors
EPIC rectangular
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Engineered for compact plug configurations, the Lapp 10432500 H-Q 5 BC female insert delivers a reliable crimp-termination interface for specialized machinery. Engineers incorporate these robust connector blocks to protect sensitive signal lines in industrial automation settings.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- IEC: 230 V / 400 V UL: 600 V CSA: 600 V
- IEC: 16 A UL: 16 A CSA: 16 A
- Crimp termination: 0.5 - 2.5 mm²
- ETIM 5.0 Class-ID: EC000438
- ETIM 5.0 Class-Description: Contact insert for industrial connectors
- ETIM 6.0 Class-ID: EC000438
- ETIM 6.0 Class-Description: Contact insert for industrial connectors
More info
▲The compact and powerful standard insert is a favourite thanks to its cost-saving crimping contact.
- Compact, powerful standard insert
- Space saving, crimping contact
- Made in Europe
Benefits
- High performance crimping contacts
- PE contact with screw connection
Application range
- Machine and equipment manufacturing
- Control engineering
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000438
- ETIM 5.0 Class-Description: Contact insert for industrial connectors
Classification ETIM 6
- ETIM 6.0 Class-ID: EC000438
- ETIM 6.0 Class-Description: Contact insert for industrial connectors
Rated voltage (V)
- IEC: 230 V / 400 V
UL: 600 V
CSA: 600 V
Rated impulse voltage
- 4 kV
Rated current (A)
- IEC: 16 A
UL: 16 A
CSA: 16 A
Pollution degree
- 3
Flammability
- UL94 V-0
Contact resistance
- < 2 mOhm
Contacts
- Copper alloy, hard silver/gold-plated
Number of contacts
- 5 + PE
Termination methods
- Crimp termination: 0.5 - 2.5 mm²
Material
- PBT Polyester
Cycle of mechanical operation
- 100
Temperature range
- -40°C to +100°C, short-term up to +125°C
