> LAPP > EPIC rectangular > 10401300
LAPP 10401300 10401300 H-BE 24 BF INSERT FEMALE W. CLAMP SPRING LAPP H-BE 24 BF INSERT FEMALE W. CLAMP SPRING View larger
Images are for illustrative purposes only. Please refer to data sheet for details

10401300 H-BE 24 BF INSERT FEMALE W. CLAMP SPRING LAPP H-BE 24 BF INSERT FEMALE W. CLAMP SPRING

10401300

10401300

H-BE 24 BF INSERT FEMALE W. CLAMP SPRING

LAPP

5 Pcs.

H-BE 24 BF INSERT FEMALE W. CLAMP SPRING EPIC® H-BE 24 Cage clamp

Connectors > Contact insert for rectangular connectors
EPIC rectangular

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

The connector insert with spring-type terminal is ideal for mechanical engineering, is highly reliable and suitable for higher voltages and currents.

  • Multifunctional insert for versatile appliactions
  • Screw, crimp, cage clamp and Push-In version - freely combinable
  • Also as EPIC® H-BE 48 available

Benefits

  • Standard inserts with screw, crimp cage clamp and Push-In termination
  • The EPIC® H-BE series is suitable for applications that require a reliable connection when working with high voltages and currents

Application range

  • Mechanical engineering
  • Light & sound technology
  • Plastics industry

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000438
  • ETIM 5.0 Class-Description: Contact insert for industrial connectors

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000438
  • ETIM 6.0 Class-Description: Contact insert for industrial connectors

Rated voltage (V)

  • IEC: 500 VUL: 600 VCSA: 600 V

Rated impulse voltage

  • 6 kV

Rated current (A)

  • IEC: 16 A
    UL: 16 A
    CSA: 16 A

Pollution degree

  • 3

Flammability

  • UL94 V-2

Contact resistance

  • 1.5 - 4 mohm

Contacts

  • Copper alloy, hard silver-plated

Number of contacts

  • 24 + PE

Termination methods

  • Cage clamp termination: 0.5 - 2.5 mm²

Stripping length (mm)

  • 7

Cycle of mechanical operation

  • 100

Certifications

  • UL-tested:
    UL File Number: E75770

Temperature range

  • -40°C to +100°C, short-term up to +125°C
