View larger
Images are for illustrative purposes only. Please refer to data sheet for details
10399100 EPC MCB 4 CM LAPP EPIC MCB 4 CM FEMALE MODULE
10399100
10399100
EPC MCB 4 CM
LAPP
10 Pcs.
EPIC MCB 4 CM FEMALE MODULE
EPIC® MC Module: HE 4pole
Connectors > Modular connector (industrial connector)
EPIC rectangular
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Benefits
- The mix of different functions in one plug guarantees high flexibility
- Assembly of individual connectors, suitable for different applications
Application range
- Plant engineering
- Printing machines
- Control engineering
Classification ETIM 5
- ETIM 5.0 Class-ID: EC002641
- ETIM 5.0 Class-Description: Modular connector (industrial connector)
Classification ETIM 6
- ETIM 6.0 Class-ID: EC002641
- ETIM 6.0 Class-Description: Modular connector (industrial connector)
Rated voltage (V)
- 630 V
Rated current (A)
- 25 A
Pollution degree
- 3
Contact resistance
- < 2 mOhm
Contacts
- Copper alloy, hard silver-plated
Number of contacts
- 4
Termination methods
- Crimp termination: 0.5 - 4.0 mm²
Cycle of mechanical operation
- 100
Temperature range
- -40°C to +100°C, short-term up to +125°C
