10383700 EPIC MCB 20 CG LAPP EPIC MCB 20 CG FEMALE MODULE
10383700
10383700
EPIC MCB 20 CG
LAPP
10 Pcs.
Connectors > Modular connector (industrial connector)
EPIC rectangular
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The 10383700 EPIC MCB 20 CG LAPP EPIC MCB 20 CG FEMALE MODULE is a high-density modular connector female insert used to organize multiple control circuits within factory automation equipment. Multi-pin contact inserts slide into heavy industrial frames, providing dependable and compact signal routing for complex machinery. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Crimp termination: 0.08 - 0.56 mm²
- UL-tested: UL File Number: E75770
- ETIM 5.0 Class-ID: EC002641
- ETIM 5.0 Class-Description: Modular connector (industrial connector)
- ETIM 6.0 Class-ID: EC002641
- ETIM 6.0 Class-Description: Modular connector (industrial connector)
More info
▲The power module with 20 contacts is able to withstand a temperature of approximately +125 degrees for a short period and is suitable, for example, in control systems.
- Suitable for processing with contacts on reel
- for automated production with crimping machine
Benefits
- The mix of different functions in one plug guarantees high flexibility
- Assembly of individual connectors, suitable for different applications
Application range
- Plant engineering
- Printing machines
- Control engineering
Classification ETIM 5
- ETIM 5.0 Class-ID: EC002641
- ETIM 5.0 Class-Description: Modular connector (industrial connector)
Classification ETIM 6
- ETIM 6.0 Class-ID: EC002641
- ETIM 6.0 Class-Description: Modular connector (industrial connector)
Rated voltage (V)
- 100 V
Rated current (A)
- 4 A
Pollution degree
- 3
Contacts
- Copper alloy, gold-plated
Number of contacts
- 20
Termination methods
- Crimp termination: 0.08 - 0.56 mm²
Cycle of mechanical operation
- 50
VDE-tested
- UL-tested:
UL File Number: E75770
Temperature range
- -40°C to +100°C, short-term up to +125°C
