View larger
Images are for illustrative purposes only. Please refer to data sheet for details
10345300 EPIC MCB 8 RJ45 LAPP EPIC MCB 8 RJ45 INDUSTRIAL ETHERNET
10345300
10345300
EPIC MCB 8 RJ45
LAPP
5 Pcs.
EPIC MCB 8 RJ45 INDUSTRIAL ETHERNET
EPIC® MC Module: RJ45
Connectors > Modular connector (industrial connector)
EPIC rectangular
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲The power module has 4 power and 8 data contacts and can be used in investment construction and control systems.
CAT.5-Performance
Benefits
- The mix of different functions in one plug guarantees high flexibility
- Assembly of individual connectors, suitable for different applications
Application range
- Plant engineering
- Control engineering
Classification ETIM 5
- ETIM 5.0 Class-ID: EC002641
- ETIM 5.0 Class-Description: Modular connector (industrial connector)
Classification ETIM 6
- ETIM 6.0 Class-ID: EC002641
- ETIM 6.0 Class-Description: Modular connector (industrial connector)
Rated voltage (V)
- max. 600 V/max. 125 V
Rated current (A)
- max. 10 A/max. 1.5 A
Pollution degree
- 3
Contacts
- Copper alloy, gold-plated
Number of contacts
- 4 Power + 8 Data
Termination methods
- Power: crimp termination: 0.14 - 2.5 mm², Data: IDC/piercing termination: Cat5, AWG 24-26
Cycle of mechanical operation
- 100
Temperature range
- -20 °C ... +85 °C
