> LAPP > ÖLFLEX HEAT Temperature measurement cables > 1024341
LAPP 1024341 1024341 ÖLFLEX HEAT 125 MC 4G4 LAPP ÖLFLEX HEAT 125 MC 4G4 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1024341 ÖLFLEX HEAT 125 MC 4G4 LAPP ÖLFLEX HEAT 125 MC 4G4

1024341

1024341

ÖLFLEX HEAT 125 MC 4G4

LAPP

100 m.

ÖLFLEX HEAT 125 MC 4G4 ÖLFLEX® HEAT 125 MC

Cables > Power cable less 1 kV, for moving application
ÖLFLEX HEAT Temperature measurement cables

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

ÖLFLEX® HEAT 125 C MC - halogen free power and control cable with DNV GL certificate, special fire performance, IEC 60332-3, suitable for +125°C

  • CPR: Article number choice under www.lappkabel.com/cpr
  • Improved characteristics in the event of a fire
  • DNV GL approved

Benefits

  • For safety in areas with high density of people
  • Reduction of flame propagation, density and toxicity of smoke gases in event of fire
  • Minimises damage to buildings and equipment caused by the formation of toxic acid fumes in fires
  • Certified for maritime applications

Application range

  • For the wiring and connection of lighting, heating appliances, control cabinets, and distributors in mechanical and plant engineering
  • For use in traffic regulation systems and outdoors
  • Coil winding, electromagnets, pumps, electrical systems
  • Heat treatment plants, pressure die casting, heating and cooling technology
  • For outdoor applications

Product features

  • Fire behaviour:
    - Halogen-free (IEC 60754-1)
    - No corrosive gases (IEC 60754-2)
    - Low smoke density (IEC 61034-2)
    - Flame-retardant (IEC 60332-1-2,
    NF C 32-070 (C1) and
    NF-F 16-101 (Class C))
    - Low toxicity (EN 50305)
  • No flame-propagation according to IEC 60332-3-22, IEC 60332-3-24 and IEC 60332-3-25 (Flame spread on vertical cable bundle)
  • Oil-resistant acc. IEC 60227-1 (ST9) and EN 50264-1 (EM104)
  • UV-resistant according to ISO 4892-2
  • Ozone-resistant according to EN 50396

Norm references / Approvals

  • DNV GL approved
  • Based on EN 50525-3-21 and EN 50525-3-41

Product Make-up

  • Fine-wire, tinned-copper conductor
  • Electron beam cross-linked polyolefin copolymer insulation
  • Cores twisted in layers
  • Outer sheath: electron beam cross-linked polyolefin copolymer, black

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC001578
  • ETIM 5.0 Class-Description: Flexible cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC001578
  • ETIM 6.0 Class-Description: Flexible cable

Core identification code

  • Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
  • From 6 cores: black with white numbers

Conductor stranding

  • Fine wire according to VDE 0295,
    class 5/IEC 60228 class 5

Minimum bending radius

  • Occasional flexing: 15 x outer diameter
  • Fixed installation: 4 x outer diameter

Nominal voltage

  • Up to 1.0mm² U0/U 300/500 V
    From 1.5mm² U0/U 450/750 V
  • 0.6/1kV from 1.5 mm² in the case of fixed and protected installation

Test voltage

  • 4000 V

Protective conductor

  • G = with GN-YE protective conductor
  • X = without protective conductor

Temperature range

  • Occasional flexing: -35 °C to +120 °C
  • Fixed installation: -55°C to +125°C
    Temporary (3.000h): up to +145°C
