View larger
Images are for illustrative purposes only. Please refer to data sheet for details
412439 IME COMPENSATOR
412439
412439
IME
1 Pcs.
COMPENSATOR
Impedance compensator for 230V~ - 50/60Hz relay
Automation > Auxiliary device for distribution board devices
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲
Compensator - Allows control of standard 230V~ remote switches by means of illuminated buttons - Connects to the terminal blocks of the remote switch coil - For an absorbed current of 3 to 6 mA (e.g.: 6 to 11 consumption buttons 0.5 mA) connect 1 compensator - For an absorbed current of 6 to 9 mA (e.g.: 12 to 17 consumption buttons 0.5 mA) connect 2 compensators - Impedance compensator for remote switches - 230V~ - 50/60 Hz - Number of modules: 1. CX³ auxiliaries and compensator - for standard switches.
| Equipment Installation | Auxiliary switch/relay |
|---|---|
| function | Remote device |
| Width in number of modular spaces | 1 |
| Nominal voltage | 230 V |
| Type of voltage | AC |
|---|---|
| Self-tested for residual current function | No |
| Suitable for max.. No. of Poles of Main Contact Unit (Total) | 4 |
| Suitable for max.. Main Contact Unit Amperage | 16 A |
| Feature Name | Feature Value |
|---|---|
| Function (EF000030) | Remote drive |
| Width in number of modular spacings (EF002950) | 1 |
| Suitable for max. current main contact unit (EF008730) | 16 A |
| Voltage type (EF000187) | AC |
| With auto test for earth leakage function (EF008727) | No |
| Rated voltage (EF000228) | 230 V |
| Device fitting (EF007826) | Auxiliary switch / relay |
| Suitable for max. number of poles main contact unit (total) (EF008729) | 4 |
