Wall mounted, 300x200x155 AFS03021-316 Mural, 300x200x155, toilet, 1 door, with MP, stainless steel 316, IP66 Wall mounted, 300x200x155, Hygienic encl., 1-door, with MP, stainless 316, IP66

Automation > Enclosure/switchgear cabinet (empty)
Stainless steel enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eldon wall-mounted enclosure provides a rugged stainless steel housing for sensitive electronic and electrical controls in harsh environments. These compact junction boxes protect internal instrumentation from corrosive elements and liquid exposure. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 300 mm
  • Width: 200 mm
  • Depth: 155 mm
  • Material: Stainless Steel 316L
  • Panel Size: 275 x 150 mm
  • Max Mounting Depth: 135 mm
  • Degree of Slope: 20 °
  • Finish: Brushed
  • Color: Unpainted
  • Latch Quantity: 1
  • Weight: 4.5 kg
  • UPC: 783510119782
  • EAN: 8713574191082
  • Standard Packaging Quantity: 1.0000
  • Packing Quantity: 1.0000
  • Width (EF000008): 200.00 mm

More info

▲

Features

  • Body: Angled 8 to 20°, the sloped-top roof provides a 10 mm overhang to drain liquids and other debris away from the front door. Folded and seam welded. For ease of installation, each back corner of the enclosure is laser-marked to precisely indicate where to drill holes and affix AWS wall mounting brackets.
  • Additional information: In environments known for quick temperature changes, consideration to condensation should be taken. Please see the thermal management section.
  • Protection: Corresponds with IP 66, TYPE 4X, 12, IK 10.
  • Mounting plate: On the top and bottom there are holes to facilitate cable fixing. Fixed onto M8 press welded studs to the rear of the enclosure. All sides, from 800 mm and above, are strengthened by folded edges.
  • Material: AISI 304L / AISI 316L pre-grained stainless steel. Body: 1.5 mm. Door: 1.5 mm / 2 mm for enclosures with a height of 1000 mm or greater. Mounting plate: 2.5 mm galvanized steel.
  • Lock: Zamak double-bit 3 mm lock, with 90° movement. Stainless steel lock and other locks available on request.
  • Finish: 400 pre-grained stainless steel.
  • Door: Corner formed in one piece. Surface mounted with 130° opening. Concealed AISI 304 stainless steel hinges with captive pin. Can be mounted to give left or right hand opening (Machining is required). Sealing is ensured by an injected polyurethane gasket. For AISI 316L, sealing is ensured by an injected silicone gasket.
  • Delivery: Enclosure with door, mounting plate, metallic key and mounting accessories.
  • Cable access: No gland openings as standard.
  • Cable access: No gland openings as standard
  • Additional information: In environments known for quick temperature changes, consideration to condensation should be taken; please see the thermal management section
Atributo del producto Valor
Height300 mm
Width200 mm
Depth155 mm
MaterialStainless Steel 316L
Panel Size275 x 150 mm
Max Mounting Depth135 mm
Degree of Slope20 °
FinishBrushed
ColorUnpainted
Latch Quantity1
Weight4.5 kg
UPC783510119782
EAN8713574191082
Standard Packaging Quantity1.0000
Packing Quantity1.0000

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
