ELDON ADR1001030 ADR1001030 ELDON Wall mounted, 1000x1000x300 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

ADR1001030 ELDON Wall mounted, 1000x1000x300

ADR1001030

1001030

ELDON

1 Pcs.

Wall mounted, 1000x1000x300 Mural, 1000x1000x300, compact, 2-door, with MP, stainless 304, IP55 Double Door Enclosure, ADR, 1000x1000x300mm, Brushed, Stainless 304

Automation > Enclosure/switchgear cabinet (empty)
Stainless steel enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Features

  • Material: AISI 304L / AISI 316L pre-grained stainless steel. Body: 1.5 mm. Door: 2 mm. Mounting plate: 2.5 mm galvanized steel.
  • Body: Folded and seam welded. For ease of installation, each back corner of the enclosure is laser-marked to precisely indicate where to drill holes and affix AWS wall mounting brackets.
  • Door: Corner formed in one piece. Surface mounted, with 130° opening. Concealed AISI 304 stainless steel hinges with captive pin. Sealing is ensured by an injected polyurethane gasket. For AISI 316L, sealing is ensured by an injected silicone gasket. Inner M6 welded studs to mount optional door profiles MMDP.
  • Lock: nVent HOFFMAN customized zamak double-bit 3 mm lock, with 90° movement and anti-vibration mechanism. Espagnolette three point locking. Stainless steel lock and other versions are available as accessories.
  • Mounting plate: The mounting plate is marked vertically at 10 mm intervals, for easy horizontal positioning of equipment. On the top and bottom there are holes to facilitate cable fixing. Fixed onto M8 press welded studs to the rear of the enclosure. All sides, from 800 mm and above, are strengthened by folded edges. By using the AMG accessory, the mounting plate position can be adjusted to any depth.
  • Cable access: No gland plate openings as standard, to maximise sealing and cleanliness.
  • Finish: 400 pre-grained stainless steel.
  • Protection: Corresponds with IP 55, TYPE 12, IK 10.
  • Delivery: Enclosure with door, mounting plate, metallic key and mounting accessories.
  • Additional information: For outdoor environments exposed to precipitation, the use of a rain hood is advised. Also in environments known for quick temperature changes, consideration to condensation should be taken. Please see the thermal management section.
Atributo del producto Valor
Height1000 mm
Width1000 mm
Depth300 mm
MaterialStainless Steel 304
Panel Size970 x 950 mm
Max Mounting Depth282 mm
FinishBrushed
ColorUnpainted
Body Thickness1.5 mm
Door Thickness2 mm
Latch Quantity1
Weight70 kg
UPC783510117337
EAN8713574120303
Standard Packaging Quantity1.0000
Packing Quantity1.0000
