ELDON DABP080809GE DABP080809GE ELDON Terminal box, 80x82x86 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

DABP080809GE ELDON Terminal box, 80x82x86

DABP080809GE

080809

ELDON

1 Pcs.

Terminal box, 80x82x86 Box for terminals, 80x82x86, without PW, ABS, IP66 Terminal box, 80x82x86, no MP, ABS, IP66

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Terminal box DABP080809GE manufactured by Eldon is a small ABS protective housing built for containing wire splices, terminals, and low-voltage electrical connections.

Compact enclosures of this nature are commonly utilized in automation and building services to maintain safe, enclosed connection points for sensor and control lines. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height (H): 80mm
  • Width (W): 82mm
  • Depth (D): 56mm
  • Max Mounting Depth: 72mm
  • Weight: 0.1kg
  • Material: ABS
  • Finish: Smooth
  • Color: Light Gray
  • UPC: 783510464325
  • EAN: 6418677177361
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Mounting method (EF000003): Surface mounted
  • Type of covering (EF000339): Cover
  • Cover model (EF009212): Closed
  • Transparent cover/door (EF006244): false

More info

▲

Features

  • Description: ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance.
  • Material: Body: ABS. Plain cover: ABS. Transparent cover: polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +60 °C.
  • Flammability: UL94 HB.
  • Protection: IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C).
  • Finish: RAL 7035.
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide.
  • Low UV radiation resistance
  • Polyurethane gasket integrated in the box cover
  • Temperature resistance: -40 °C to +60 °C
  • Flammability: UL94 HB
  • Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide
Atributo del producto Valor
Height (H)80mm
Width (W)82mm
Depth (D)56mm
Max Mounting Depth72mm
Weight0.1kg
MaterialABS
FinishSmooth
ColorLight Gray
UPC783510464325
EAN6418677177361
Standard Packaging Quantity1
Packing Quantity1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
