ELDON DABP080806GE DABP080806GE ELDON Terminal box, 80x82x56 DABP080806GE View larger
Images are for illustrative purposes only. Please refer to data sheet for details

DABP080806GE ELDON Terminal box, 80x82x56 DABP080806GE

DABP080806GE

080806

ELDON

1 Pcs.

Terminal box, 80x82x56 DABP080806GE Box for terminals, 80x82x56, without PW, ABS, IP66 Terminal box, 80x82x56, no MP, ABS, IP66

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The DABP080806GE ELDON Terminal box is a compact ABS surface-mounted enclosure used for enclosing wire terminations, splices, and low-voltage connection points. Small terminal boxes provide insulated, dust-resistant junctions that protect delicate electrical connections in commercial and industrial settings.

Specific pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Height: 80mm
  • Width: 82mm
  • Depth: 86mm
  • Max Mounting Depth: 42mm
  • Weight: 0.1kg
  • Material: ABS
  • Finish: Smooth
  • Color: Light Gray
  • UPC: 783510464264
  • EAN: 6418677177354
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Mounting method (EF000003): Surface mounted
  • Type of covering (EF000339): Cover
  • Cover model (EF009212): Closed
  • Transparent cover/door (EF006244): false

More info

▲

Features

  • Description: ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance.
  • Material: Body: ABS. Plain cover: ABS. Transparent cover: polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +60 °C.
  • Flammability: UL94 HB.
  • Protection: IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C).
  • Finish: RAL 7035.
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide.
  • Low UV radiation resistance
  • Polyurethane gasket integrated in the box cover
  • Temperature resistance: -40 °C to +60 °C
  • Flammability: UL94 HB
  • Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide
Atributo del producto Valor
Height80mm
Width82mm
Depth86mm
Max Mounting Depth42mm
Weight0.1kg
MaterialABS
FinishSmooth
ColorLight Gray
UPC783510464264
EAN6418677177354
Standard Packaging Quantity1
Packing Quantity1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
