ELDON HALP082506GE HALP082506GE ELDON Terminal box, 80x250x57 HALP082506GE View larger
Images are for illustrative purposes only. Please refer to data sheet for details

HALP082506GE ELDON Terminal box, 80x250x57 HALP082506GE

HALP082506GE

082506

ELDON

1 Pcs.

Terminal box, 80x250x57 HALP082506GE Box for terminals, 80x250x57, without MP, aluminium, IP66 Terminal box, 80x250x57, no MP, aluminium, IP66

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for specialized wiring applications, this Eldon aluminum terminal box (HALP082506GE) provides rugged housing for electronic components and electrical connections. Aluminum construction offers superior durability and electromagnetic shielding performance in challenging industrial settings.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Height (H): 80mm
  • Width (W): 249mm
  • Depth (D): 57mm
  • Material: Aluminum
  • Finish: Powder Coated
  • Color: Silver Grey
  • Color Code: RAL 7001
  • Body Thickness: 3.5mm
  • Cover Thickness: 2.5mm
  • Cover Screw Quantity: 4
  • Weight: 0.7kg
  • Thread Type: M4
  • UPC: 783510482244
  • EAN: 8713574089235
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1

More info

▲

Features

  • Material: Aluminium alloy EN AC-47100.
  • Gasket: Standard supply fitted with a polyurethane gasket. Silicone, neoprene and EPDM gaskets are available on request.
  • Temperature resistance: -30 ºC to +80 ºC.
  • Protection: IP 66, 67, IK 09, 08 for HALP050503GE.
  • Finish: RAL 7001.
  • Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
  • Delivery: Body and cover are manufactured from aluminum, cover screws are made of stainless steel.
Atributo del producto Valor
Height (H)80mm
Width (W)249mm
Depth (D)57mm
MaterialAluminum
FinishPowder Coated
ColorSilver Grey
Color CodeRAL 7001
Body Thickness3.5mm
Cover Thickness2.5mm
Cover Screw Quantity4
Weight0.7kg
Thread TypeM4
UPC783510482244
EAN8713574089235
Standard Packaging Quantity1
Packing Quantity1
