ELDON DABP233009GE DABP233009GE ELDON Terminal box, 230x300x86 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

DABP233009GE ELDON Terminal box, 230x300x86

DABP233009GE

233009

ELDON

1 Pcs.

Terminal box, 230x300x86 Box for terminals, 230x300x86, without PW, ABS, IP66 Terminal box, 230x300x86, no MP, ABS, IP66

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Eldon DABP233009GE terminal box is a surface-mounted enclosure designed to house, organize, and protect electrical connections, terminal blocks, and small control components in industrial environments. Enclosures of this classification safeguard sensitive wiring from dust, physical contact, and environmental elements.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Height (H): 230mm
  • Width (W): 300mm
  • Depth (D): 86mm
  • Max Mounting Depth: 72mm
  • Weight: 0.85kg
  • Material: ABS
  • Finish: Smooth
  • Color: Light Gray
  • UPC: 783510464714
  • EAN: 6418677187018
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Mounting method (EF000003): Surface mounted
  • Type of covering (EF000339): Cover
  • Cover model (EF009212): Closed
  • Transparent cover/door (EF006244): No

More info

▲

Features

  • Description: ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance.
  • Material: Body: ABS. Plain cover: ABS. Transparent cover: polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +60 °C.
  • Flammability: UL94 HB.
  • Protection: IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C).
  • Finish: RAL 7035.
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide.
  • Low UV radiation resistance
  • Polyurethane gasket integrated in the box cover
  • Temperature resistance: -40 °C to +60 °C
  • Flammability: UL94 HB
  • Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide
Atributo del producto Valor
Height (H)230mm
Width (W)300mm
Depth (D)86mm
Max Mounting Depth72mm
Weight0.85kg
MaterialABS
FinishSmooth
ColorLight Gray
UPC783510464714
EAN6418677187018
Standard Packaging Quantity1
Packing Quantity1
