ELDON SABP181810GE SABP181810GE ELDON Terminal box, 175x175x100 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SABP181810GE ELDON Terminal box, 175x175x100

SABP181810GE

181810

ELDON

1 Pcs.

Terminal box, 175x175x100 Box for terminals, 175x175x100, grey cover, without PW, ABS, IP66 Terminal box, 175x175x100, Grey cover, no MP, ABS, IP66

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Terminal box SABP181810GE from Eldon functions as a compact ABS enclosure designed to protect electrical junctions, wiring terminations, and small control elements.

ABS junction boxes offer reliable lightweight protection for localized wiring networks in commercial buildings and industrial control setups. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height (H): 175mm
  • Width (W): 175mm
  • Depth (D): 100mm
  • Max Mounting Depth: 85.5mm
  • Weight: 0.5kg
  • Material: ABS
  • Finish: Smooth
  • Color: Light Gray
  • Color Code: RAL 7035
  • UPC: 783510527235
  • EAN: 6418677177750
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Mounting method (EF000003): Surface mounted
  • Type of covering (EF000339): Cover
  • Cover model (EF009212): Closed

More info

▲

Features

  • Description: ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance.
  • Material: Body: ABS. Plain cover: ABS. Transparent cover: polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +60 °C.
  • Flammability: UL94 HB.
  • Protection: IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C).
  • Finish: RAL 7035.
  • Delivery: Body, cover, cover screws manufactured from polyamide and mounting screws.
  • Customers can choose terminal boxes that meet their size requirements, off the shelf
  • The installed components inside the terminal box will be safe and secure due to the high protection degree
  • Customers can receive terminal boxes with a short delivery time, that match their size requirements
  • This will also remove any extra costs due to oversizing
  • Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the terminal box
  • The mounting plate, SMP, and DIN profiles, DR, have to be ordered separately, in order to complete the installation of the terminal box
  • Note: Terminal box, with polycarbonate transparent cover fitted, can be ordered by replacing GE with TE in the item number
  • erminal box manufactured from polycarbonate can be ordered by replacing SABP with SPCP in the item number
Atributo del producto Valor
Height (H)175mm
Width (W)175mm
Depth (D)100mm
Max Mounting Depth85.5mm
Weight0.5kg
MaterialABS
FinishSmooth
ColorLight Gray
Color CodeRAL 7035
UPC783510527235
EAN6418677177750
Standard Packaging Quantity1
Packing Quantity1
