HALP163609GE ELDON Terminal box, 160x360x90 HALP163609GE
HALP163609GE
163609
ELDON
1 Pcs.
Automation > Empty cabinet
Terminal Boxes
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Securing sensitive electrical wiring connections and small terminal strips from dust and moisture is achieved using this Eldon aluminum terminal box. These enclosures are commonly mounted onto factory machinery to provide reliable interface protection.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height (H): 160mm
- Width (W): 359mm
- Depth (D): 90mm
- Material: Aluminum
- Finish: Powder Coated
- Color: Silver Grey
- Color Code: RAL 7001
- Body Thickness: 4.1mm
- Cover Thickness: 3.7mm
- Cover Screw Quantity: 4
- Weight: 2.7kg
- UPC: 783510482466
- EAN: 8713574089310
- Standard Packaging Quantity: 1
- Packing Quantity: 1
- Mounting method (EF000003): Surface mounted
More info
▲Features
- Material: Aluminium alloy EN AC-47100.
- Gasket: Standard supply fitted with a polyurethane gasket. Silicone, neoprene and EPDM gaskets are available on request.
- Temperature resistance: -30 ºC to +80 ºC.
- Protection: IP 66, 67, IK 09, 08 for HALP050503GE.
- Finish: RAL 7001.
- Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
- Delivery: Body and cover are manufactured from aluminum, cover screws are made of stainless steel.
| Atributo del producto | Valor |
|---|---|
| Height (H) | 160mm |
| Width (W) | 359mm |
| Depth (D) | 90mm |
| Material | Aluminum |
| Finish | Powder Coated |
| Color | Silver Grey |
| Color Code | RAL 7001 |
| Body Thickness | 4.1mm |
| Cover Thickness | 3.7mm |
| Cover Screw Quantity | 4 |
| Weight | 2.7kg |
| UPC | 783510482466 |
| EAN | 8713574089310 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
