ELDON SABP131310GE SABP131310GE ELDON Terminal box, 125x125x100 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SABP131310GE ELDON Terminal box, 125x125x100

SABP131310GE

131310

ELDON

1 Pcs.

Terminal box, 125x125x100 Box for terminals, 125x125x100, grey cover, without PW, ABS, IP66 Terminal box, 125x125x100, Grey cover, no MP, ABS, IP66

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A compact SABP131310GE ELDON Terminal box, 125x125x100 serves as a secure junction point for terminating wires and safeguarding small electrical components against dust and moisture. Terminal boxes are essential across industrial sites for maintaining neat and safe cable connections.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Height (H): 125mm
  • Width (W): 125mm
  • Depth (D): 100mm
  • Max Mounting Depth: 85.5mm
  • Weight: 0.3kg
  • Material: ABS
  • Finish: Smooth
  • Color: Light Gray
  • Color Code: RAL 7035
  • UPC: 783510527143
  • EAN: 6418677177682
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Mounting method (EF000003): Surface mounted
  • Type of covering (EF000339): Cover
  • Cover model (EF009212): Closed

More info

▲

Features

  • Description: ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance.
  • Material: Body: ABS. Plain cover: ABS. Transparent cover: polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +60 °C.
  • Flammability: UL94 HB.
  • Protection: IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C).
  • Finish: RAL 7035.
  • Delivery: Body, cover, cover screws manufactured from polyamide and mounting screws.
  • Customers can choose terminal boxes that meet their size requirements, off the shelf
  • The installed components inside the terminal box will be safe and secure due to the high protection degree
  • Customers can receive terminal boxes with a short delivery time, that match their size requirements
  • This will also remove any extra costs due to oversizing
  • Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the terminal box
  • The mounting plate, SMP, and DIN profiles, DR, have to be ordered separately, in order to complete the installation of the terminal box
  • Note: Terminal box, with polycarbonate transparent cover fitted, can be ordered by replacing GE with TE in the item number
  • erminal box manufactured from polycarbonate can be ordered by replacing SABP with SPCP in the item number
Atributo del producto Valor
Height (H)125mm
Width (W)125mm
Depth (D)100mm
Max Mounting Depth85.5mm
Weight0.3kg
MaterialABS
FinishSmooth
ColorLight Gray
Color CodeRAL 7035
UPC783510527143
EAN6418677177682
Standard Packaging Quantity1
Packing Quantity1
