Images are for illustrative purposes only. Please refer to data sheet for details
ESFC406 ELDON Swing frame, 2000 ESFC406
ESFC406
10000
ELDON
1 Pcs.
Swing frame, 2000 ESFC406
Rotating frame, 2000
Full Height Swing Frames, ESFC, 1867x499x80mm, Zinc Plated, Mild Steel
Automation > Divider panel (switchgear cabinet)
Steel Floor Standing Enclosures
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eldon swing frame designed to provide hinged, accessible mounting for 19-inch equipment and modular control components within floor-standing enclosures. Part number ESFC406 allows easy operational access to panel instruments.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Modular spacing (EF000394): 483.00 mm
- Suitable for enclosure building width (EF000326): 19.69 mm
- Width (EF000008): 499.00 mm
- Height (EF000040): 1867.00 mm
- Material (EF002169): Steel
- With cable entry (EF000325): No
- Number of height units (EF003561): 40.00
- With lock (EF006306): Yes
- Construction type (EF000767): Assembly kit
- For internal separation form 2a (EF009586): No
- For internal separation form 2b (EF009587): No
- For internal separation form 3a (EF009588): No
- For internal separation form 3b (EF009589): No
- For internal separation form 4a (EF009590): No
- For internal separation form 4b (EF009591): No
More info
▲Features
- Description: Full height swing frame for 19” components allowing left and right hand opening. Can be used in steel, combinable and compact enclosures. Hinges designed to give extra build-in depth. Adjustable top hinge for square mounting of the swing frame. Rigid W-shaped frame profile for heavy equipment. Zinc plated 19" vertical profiles for direct earthing of the mounted components. Standard equipped with 130° hinges. Can also be mounted on the side of 600 mm deep floor standing enclosures. For steel, combinable enclosures use transversal support bars ESFB in combination with VBD if required. Adjustable in depth by steps of 12.5 mm.
- Maximum load: 1800N, supplied with a self positioning device.
- Lock: Two 3 mm double-bit locks.
- Material: 19" vertical profiles 2 mm zinc plated steel. Frame: vertical profiles 2 mm and horizontal profiles 3 mm.
- Pack quantity: 1 swing frame with hinges.
- Mounting requirements: ESFC for 600 mm, 800 mm, 1000 mm, 1200 mm wide steel, combinable enclosures. Add ESFB for mounting in a steel, combinable enclosure.
