View larger
Images are for illustrative purposes only. Please refer to data sheet for details
RFU10015R5 ELDON Roof fan Air flow 750 m3/h RFU10015R5
RFU10015R5
10015
ELDON
1 Pcs.
Roof fan Air flow 750 m3/h RFU10015R5
Ceiling fan, 750 m3/h, 115 V, IP54
Roof fan Air flow 750 m3/h, 115V, IP54
Automation > Ventilator (switchgear cabinet)
General Accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Features
- Description: Roof fan unit for mounting on the top of the enclosure providing forced ventilation. The unit is easily installed with a quick fastening system, and the required cutout is the same for the different air flow.
- Material: Painted mild steel, and injection-moulded thermoplastic (ABS-FR) self extinguishing, UL94V0.
- Temperature range: -15 °C to +55 °C.
- Type of connection: Terminal strip.
- Finish: RAL 7035.
- Pack quantity: One roof fan unit.
- Roof fan unit for mounting on the top of the enclosure providing forced ventilation
- The unit is easily installed with a quick fastening system, and the required cutout is the same for the different air flow
- Temperature range: -15 °C to +55 °C
- Bearing Type: Ball
- Protection: IP33 No filtermat; IP54 Filtermat
| Atributo del producto | Valor |
|---|---|
| Free Airflow | 750*m³/h |
| Height | 148mm |
| Width | 470mm |
| Depth | 470mm |
| Cutout Size | 291 x 291mm |
| Nominal Voltage | 115V |
| Protection Rating | IP33; IP54 |
| Material | Mild Steel |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Frequency | 50/60 HzHz |
| Connection Type | Terminal Strip |
| Filter Efficiency | 90% |
| Weight | 4.78kg |
| UPC | 783510526955 |
| EAN | 8713574161849 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
| Feature Name | Feature Value |
|---|---|
| Number of fans (EF000928) | 1.00 |
| Operating voltage AC 60 Hz (EF008207) | 115.00 V |
| Voltage type (EF000187) | AC |
| Built as slide-in ventilator (EF007126) | Yes |
| Air circulator (EF007516) | No |
| Roof ventilator (EF007099) | Yes |
| With filter (EF006013) | No |
| Volume flow, freeblowing (EF007173) | 750.00 m³/h |
| Rated power (EF007051) | 160.00 W |
| EMC-version (EF001062) | No |
| Degree of protection (IP) (EF005474) | IP54 |
| Mounting method (EF000003) | Snap mounting |
| Suitable for 19 inch rack mounting (EF000337) | No |
| Colour (EF000007) | Grey |
| RAL-number (EF000116) | 7.04 |
| Width (EF000008) | 470.00 mm |
| Height (EF000040) | 148.00 mm |
| Depth (EF000049) | 470.00 mm |
