ELDON RFU10013R5 RFU10013R5 ELDON Roof fan Air flow 1000 m3/h RFU10013R5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

RFU10013R5 ELDON Roof fan Air flow 1000 m3/h RFU10013R5

RFU10013R5

10013

ELDON

1 Pcs.

Roof fan Air flow 1000 m3/h RFU10013R5 Ceiling fan, 1000 m3/h, 115 V, IP33 Roof fan Air flow 1000 m3/h, 115V, IP33

Automation > Ventilator (switchgear cabinet)
General Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Features

  • Description: Roof fan unit for mounting on the top of the enclosure providing forced ventilation. The unit is easily installed with a quick fastening system, and the required cutout is the same for the different air flow.
  • Material: Painted mild steel, and injection-moulded thermoplastic (ABS-FR) self extinguishing, UL94V0.
  • Temperature range: -15 °C to +55 °C.
  • Type of connection: Terminal strip.
  • Finish: RAL 7035.
  • Pack quantity: One roof fan unit.
  • Roof fan unit for mounting on the top of the enclosure providing forced ventilation
  • The unit is easily installed with a quick fastening system, and the required cutout is the same for the different air flow
  • Temperature range: -15 °C to +55 °C
  • Bearing Type: Ball
  • Protection: IP33 No filtermat; IP54 Filtermat
Atributo del producto Valor
Free Airflow1000*m³/h
Height148mm
Width470mm
Depth470mm
Cutout Size291 x 291mm
Nominal Voltage115V
Protection RatingIP33; IP54
MaterialMild Steel
FinishPowder Coated
ColorLight Gray
Color CodeRAL 7035
Frequency50/60Hz
Connection TypeTerminal Strip
Weight4.78kg
UPC783510526948
EAN8713574161597
Standard Packaging Quantity1
Packing Quantity1

ETIM for RFU10013R5 Cabinets and enclosures (EC000320)
Feature Name Feature Value
Number of fans (EF000928) 1.00
Operating voltage AC 60 Hz (EF008207) 115.00 V
Voltage type (EF000187) AC
Built as slide-in ventilator (EF007126) Yes
Air circulator (EF007516) No
Roof ventilator (EF007099) Yes
With filter (EF006013) No
Volume flow, freeblowing (EF007173) 1.00 m³/h
Rated power (EF007051) 160.00 W
EMC-version (EF001062) No
Degree of protection (IP) (EF005474) IP33
Mounting method (EF000003) Snap mounting
Suitable for 19 inch rack mounting (EF000337) No
Colour (EF000007) Grey
RAL-number (EF000116) 7.04
Width (EF000008) 470.00 mm
Height (EF000040) 148.00 mm
Depth (EF000049) 470.00 mm
