ELDON CUH38004 CUH38004 ELDON Roof cooling unit 3800W CUH38004 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CUH38004 ELDON Roof cooling unit 3800W CUH38004

CUH38004

38004

ELDON

1 Pcs.

Roof cooling unit 3800W CUH38004 Eq. air-cond. roof 3800 W, 400-460 V, sheet steel, IP54 Roof cooling unit 3800W, 400-460V, Mild steel, IP54

Automation > Air conditioner (switchgear cabinet)
General Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Mounted to the top of control enclosures, the CUH38004 ELDON Roof cooling unit 3800W CUH38004 manages thermal loads where vertical side-wall space is limited. Roof-mounted cooling units utilize internal air circulation loops to keep sensitive automation hardware operating safely across industrial applications. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 480mm
  • Width: 800mm
  • Depth: 450mm
  • Material: Mild Steel
  • Finish: Powder Coated
  • Color: Light Gray
  • RAL: 7035
  • Phase Quantity: 3
  • Frequency: 50/60 HzHz
  • UPC: 783510461751
  • EAN: 8713574184145
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Model (EF000010): Air/air
  • Operating voltage AC 50 Hz (EF008206): 400.00 V
  • Operating voltage AC 60 Hz (EF008207): 460.00 V
  • Voltage type (EF000187): AC

More info

▲

Features

  • Roof cooling unit with a IP 54 protection degree
  • The cooling unit can provides cooling to enclosure's that do not have enough space on the door or side panels whether standalone or as part of an enclosure assembly
  • Floor standing enclosures can be cooled independently of each other, if required; This avoids cooling the entire enclosure assembly, reducing the amount of energy required, saving unnecessary costs
  • To minimise how much energy the cooling unit consumes, it is recommended to install the door switch, DSW01; Once installed, the door switch will turn the cooling unit off, once the door is opened
  • High performance cooling unit for roof mounting, the air conditioners cover a cooling capacity range from 600 W to 3800 W
  • Condensation management system, which prevents all condensation from penetrating into the enclosure
  • All models are equipped with a condensation dissipator, from 1400 W up to 3800 W units
  • Easy installation, with a quick release mounting frame
  • Common to all models is the self cleaning condenser coil, which eliminates the necessity for an air filter, avoiding standard maintenance
  • All models are equipped with digital display
  • The cooling capacity for specific conditions are indicated in the diagrams
  • Ozone friendly refrigerant R134a
  • Temperature limits inside: +25 °C to +45 °C
  • Temperature limits outside: +20 °C to +55 °C
Atributo del producto Valor
Height480mm
Width800mm
Depth450mm
MaterialMild Steel
FinishPowder Coated
ColorLight Gray; RAL 7035
Phase Quantity3
Frequency50/60 HzHz
UPC783510461751
EAN8713574184145
Standard Packaging Quantity1
Packing Quantity1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
