DP08006R5 ELDON Partial door, 800x600 DP08006R5
DP08006R5
08006
ELDON
1 Pcs.
Automation > Door/operating panel (switchgear cabinet)
Power and distribution
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eldon DP08006R5 partial door is designed for compartmentalized freestanding enclosures, allowing segmented access to specific sections of an industrial control system. Partial enclosure doors help isolate different operating areas and protect internal wiring from external contaminants. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height: 800mm
- Width: 600mm
- Depth: 17mm
- Enclosure Material: Mild Steel
- Product Family: Free-Standing
- Material: Mild Steel
- Finish: Powder Coated
- Color: Light Gray
- Color Code: RAL 7035
- UPC: 783510470319
- EAN: 8713574123205
- Standard Packaging Quantity: 1
- Packing Quantity: 1
- Width (EF000008): None mm
- Height (EF000040): None mm
- Depth (EF000049): None mm
More info
▲Features
- Description: To divide the enclosure front into sections when used in conjunction with the horizontal divider CDH/CHDK. Equipped with double-bit 3 mm lock (1 lock up to 400 mm, over 400 mm height 2 locks).
- Material: 1.75 mm steel plate.
- Finish: RAL 7035 structured powder coating.
- Protection: Complies with IP 44.
- Pack quantity: 1 door with hinges, locks and mounting accessories.
- Mounting requirements: Add CDH for MC frames and use CDHK for MK frames. Use DPC/DPCV for top and bottom panels.
| Atributo del producto | Valor |
|---|---|
| Height | 800mm |
| Width | 600mm |
| Depth | 17mm |
| Enclosure Material | Mild Steel |
| Product Family | Free-Standing |
| Material | Mild Steel |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| UPC | 783510470319 |
| EAN | 8713574123205 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
