ELDON UMPZ100500 UMPZ100500 ELDON Mounting plate, 1000x500 UMPZ100500 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

UMPZ100500 ELDON Mounting plate, 1000x500 UMPZ100500

UMPZ100500

100500

ELDON

1 Pcs.

Mounting plate, 1000x500 UMPZ100500 Mounting plate, 1000x500, galvanized steel

Automation > Mounting plate for distribution board
Polyester Uniplast enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A galvanized steel backing panel, the UMPZ100500 ELDON Mounting plate, 1000x500 UMPZ100500 offers a solid foundational surface for securing electrical components, terminals, and control gear inside protective enclosures. These panels are standard components in industrial automation systems, enabling flexible layout design for internal equipment. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 890mm
  • Width: 390mm
  • Compatible Enclosure Height: 1000mm
  • Depth: 9mm
  • Compatible Enclosure Width: 500mm
  • Material: Galvanized Steel
  • Finish: Plated
  • Thickness: 2mm
  • Enclosure Material: Polyester
  • UPC: 783510531775
  • EAN: 8713574101197
  • Standard Packaging Quantity: 1
  • Packing Quantity: 1
  • Height (EF000040): 1.00 mm
  • Width (EF000008): 500.00 mm
  • Material (EF002169): Steel

More info

▲

Features

  • Description: Steel mounting plate for UDP/UDPT enclosures.
  • Material: 2 mm galvanized steel.
  • Pack quantity: 1 piece.
  • Depth: 9 mm.
  • Note: UMPZ-M can be mounted in both directions.
Atributo del producto Valor
Height890mm
Width390mm
Compatible Enclosure Height1000mm
Depth9mm
Compatible Enclosure Width500mm
MaterialGalvanized Steel
FinishPlated
Thickness2mm
Enclosure MaterialPolyester
UPC783510531775
EAN8713574101197
Standard Packaging Quantity1
Packing Quantity1
