MCSL18126R5 ELDON FS Sw/gear enc. 1800x1200x600
MCSL18126R5
18126
ELDON
1 Pcs.
FS Sw/gear enc. 1800x1200x600
Self-supporting, 1800x1200x600, combinable, no door, no MP, mild steel
Combinable Floor stand. encl., MCSL-PD, 1800x1200x600, Light Gray, Mild Steel
Automation > Enclosure/switchgear cabinet (empty)
Power and distribution
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Features
- Material: Frame: 1.5 painted steel. Rear and roof panels: 1.5 mm painted steel.
- Frame: Seam welded reversed open profiles with 25 mm hole pattern according to DIN 43660. Including integrated external hole pattern.
- Rear panel: Fitted by M6 torx screws. Standard facilities for rear door mounting.
- Roof panel: Removable.
- Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud.
- Finish: RAL 7035 structured powder coating.
- Protection: IP 44, 55 TYPE 12 IK 10, depending of doors configuration.
- Mounting requirements: Standard delivery ready for combined installation. For stand-alone installation add side panels.
- Delivery: Frame, rear and roof panel. Delivery also includes earthing bolts. Delivered on a pallet with identical width of the enclosure to allow suiting without removal. All packing material is recyclable.
| Atributo del producto | Valor |
|---|---|
| Height | 1800 mm |
| Width | 1200 mm |
| Depth | 600 mm |
| Rack Units | 32 |
| Material | Mild Steel |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thickness | 1.5 mm |
| UPC | 783510497750 |
| EAN | 8713574126947 |
| Standard Packaging Quantity | 1.0000 |
| Packing Quantity | 1.0000 |
