ELDON MCD20106PER5 MCD20106PER5 ELDON Floor standing, 2000x1000x600 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MCD20106PER5 ELDON Floor standing, 2000x1000x600

MCD20106PER5

20106

ELDON

1 Pcs.

Floor standing, 2000x1000x600 Self-supporting, 2000x1000x600, combinable, 2 doors, without MP, mild steel, IP55 Modular Double Door, MCD no Plate, 2000x1000x600mm, Light Gray, Mild Steel

Automation > Enclosure/switchgear cabinet (empty)
Steel Floor Standing Enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Features

  • Material: Frame: 1.5 mm painted steel. Doors: 2 mm painted steel. Rear, roof and side panels: 1.5 mm painted steel. Mounting plate: 3 mm galvanized steel. Bottom plates: 1 mm galvanized steel.
  • Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660. Including integrated external hole pattern.
  • Doors: Mounted with four hinges. Including door frame with 25 mm hole pattern. Doors cannot be reversed. Separate doors to be ordered for left hand door locking.
  • Rear panel: Fitted by M6 torx screws. Standard facilities for rear doors mounting. Split rear panels in 1600 mm wide enclosures. RD version comes with rear door instead of rear panel.
  • Side panels: Supplied as an accessory.
  • Roof panel: Removable.
  • Lock: Espagnolette 4-point locking system in the main door and 2-point locking system in the slave door. Standard double-bit lock with 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories.
  • Bottom plates: Consists of three or four (D>600) pieces.
  • Mounting plate: Double folded and slides into position. Adjustable in depth by steps of 25 mm, with the MPD02 accessory. Supplied, attached on the outside of the enclosure packaging.
  • Earthing: All panels are earthed through their fittings and equipped with a separate earthing stud.
  • Finish: RAL 7035 structured powder coating.
  • Protection: Complies with IP55 TYPE 12 IK 10.
  • Mounting requirements: Standard delivery ready for combined installation. For stand-alone installation add side panels.
  • Delivery: Frame with fitted doors, rear panel, roof panel, bottom plates, mounting plate and door frame (not included for PER5 version). For enclosures 2200 mm height, delivery includes two CMB profiles mounted in depth. Delivery also includes earthing bolts. Delivered on a pallet which is identical to the width of the enclosure to allow baying without removal. Packing material is recyclable.
Atributo del producto Valor
Height2000 mm
Width1000 mm
Depth600 mm
Mounting Plate IncludedNo
Door/Rear PanelRear panel
MaterialMild Steel
FinishPowder Coated
ColorLight Gray
Color CodeRAL 7035
Body Thickness1.5 mm
Door Thickness2 mm
Weight200.5 kg
Panel Size832x510 mm
UPC783510491451
EAN8713574130142
Standard Packaging Quantity1.0000
Packing Quantity1.0000
