ELDON MCI18068R5 MCI18068R5 ELDON Floor standing, 1800x600x800 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MCI18068R5 ELDON Floor standing, 1800x600x800

MCI18068R5

18068

ELDON

1 Pcs.

Floor standing, 1800x600x800 Self-supporting, 1800x600x800, combinable, 1 door, no MP, mild steel, IP55 Floor stand., 1800x600x800, Combinable encl., 1-door, no MP, mild steel, IP55

Automation > Enclosure/switchgear cabinet (empty)
Steel Floor Standing Enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Features

  • Material: Frame: 1.5 mm steel plate. Door: 2 mm steel plate. Roof plate: 1.5 mm steel plate. Bottom plates: 1 mm galvanized steel. 19" profiles: 2 mm zinc plated steel
  • Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660. Including integrated external hole pattern
  • Rear door: Mounted with hinges, allowing left or right hand opening. Including door frame with 25 mm hole pattern
  • Side panels: Supplied as an accessory
  • Roof panel: Removable
  • Lock: Espagnolette 4-point locking system. Does not interfere with the enclosure inner space. Standard double-bit lock with 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories
  • Bottom plates: Consists of three or four (D>600) pieces
  • 19" profiles: Provides front and side universal 19" hole pattern. Adjustable in depth by steps of 25 mm
  • Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud
  • Finish: Frame, rear door and roof plate: RAL 7035 structured powder coating. 19" profiles: zinc plated steel
  • Protection: Complies with IP 55 TYPE 12 IK 10, when plain front door and side panels are fitted
  • Mounting requirements: Add side panels for closed sides. Front frame can be covered with FFC or fitted with a glazed or plain door
  • Delivery: Frame with fitted rear door, roof panel, bottom plates. 19" profiles at front and fixing brackets CIB. For enclosures 2200 mm height, delivery includes two CMB profiles mounted in depth. Delivery also includes earthing bolts. Delivered on a pallet which is identical to the width of the enclosure to allow baying without removal. All packing material is recyclable.
Atributo del producto Valor
Height (H)1800 mm
Width (W)600 mm
Depth (D)800 mm
MaterialMild Steel
FinishPowder Coated; Zinc Plated
ColorLight Gray
Color CodeRAL 7035
Body Thickness1.5 mm
Door Thickness2 mm
Rack Units38
Weight38 kg
UPC783510493363
EAN8713574129399
Standard Packaging Quantity1.0000
Packing Quantity1.0000

ETIM for MCI18068R5 Cabinets and enclosures (EC000261)
Feature Name Feature Value
Width (EF000008) 600.00 mm
Height (EF000040) 1.80 mm
Depth (EF000049) 800.00 mm
Material (EF002169) Steel
Surface finishing (EF006569) Powder coated
Colour (EF000007) Grey
RAL-number (EF000116) 7.04
With mounting plate (EF000118) No
Pole fastening (EF009582) No
Number of doors (EF000122) 1.00
Number of locks (EF000123) 1.00
Pitched roof (EF009278) No
EMC-version (EF001062) No
With glazed door (EF001089) No
With ventilation door (EF006279) No
With rear door (EF007381) No
Impact strength (EF004293) IK10
Degree of protection (IP) (EF005474) IP55
Degree of protection (NEMA) (EF011959) 12
