EKOM14184-SW ELDON Floor standing, 1400x1800x400
EKOM14184-SW
14184
ELDON
1 Pcs.
Automation > Enclosure/switchgear cabinet (empty)
Steel Floor Standing Enclosures
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An EKOM14184-SW Eldon floor standing enclosure provides a wide-profile aluminum housing solution designed for extensive industrial electrical and automation system integrations.
Multi-door floor-standing cabinets are widely selected for large-scale manufacturing lines to house complex PLC networks, motor control drives, and extensive terminal blocks.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height (H): 1400mm
- Width (W): 1800mm
- Depth (D): 400mm
- Door Quantity: 3
- Material: Aluminum
- Finish: Powder Coated
- Color: Light Gray
- Color Code: RAL 7035
- Thickness (T): 2mm
- Weight: 134kg
- UPC: 783510478186
- EAN: 8713574188211
- Standard Packaging Quantity: 1
- Packing Quantity: 1
- Width (EF000008): 1.80 mm
- Height (EF000040): 1.40 mm
More info
▲Features
- Body: One piece enclosure body. Integrated depth profiles with hole pattern, allowing mounting plate adjustable in depth. The frame in multiple door versions, is divided into individual modules by means of vertical dividers.
- Rainhood: Sloped rainhood with integrated rain gutter and ventilation channels in the perimeter.
- Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud.
- "Approvals: Climatic and Chemically active substances resistance according to EN61969-3 ""Mechanical structures for electronic equipment. Outdoor enclosures”."
- Bottom plates: Supplied as accessory.
- Rear panel: Fastened from the inside. Standard facilities for rear door mounting.
- Protection: Complies with IP 66 TYPE 4X, 12 IK 10, when a bottom plate is fitted.
- Material: Aluminium AlMg3. Frame: 2 mm. Door: 2 mm. Rear panel: 2 mm. Rain hood: 2 mm.
- Lock: Espagnolette 4-point locking system. Does not interfere with the enclosure inner space. Standard lift handle with security lock.
- Finish: RAL 7035 structure powder coating 100% polyester.
- Door: Double walled with top and bottom ventilation openings, allowing air flow. Mounted with concealed hinges, allowing left or right hand opening. Multiple door version has individual lockable doors.
- Delivery: Frame with fitted door with swinghandle, rear panel, rain hood. Delivery also includes earthing bolts. Delivered on a pallet which is identical to the width of the enclosure to allow baying without removal. All packing material is recyclable. Mounting plate and bottom plates are not included in the standard delivery.
| Atributo del producto | Valor |
|---|---|
| Height (H) | 1400mm |
| Width (W) | 1800mm |
| Depth (D) | 400mm |
| Door Quantity | 3 |
| Material | Aluminum |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thickness (T) | 2mm |
| Weight | 134kg |
| UPC | 783510478186 |
| EAN | 8713574188211 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
