ELDON EKOM12126 EKOM12126 ELDON Floor standing, 1200x1200x600 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

EKOM12126 ELDON Floor standing, 1200x1200x600

EKOM12126

12126

ELDON

1 Pcs.

Floor standing, 1200x1200x600 Self-supporting, 1200x1200x600, compact, 2-door, no MP, aluminium, IP66 Floor standing, 1200x1200x600, Compact enclosure, 2-door, no MP, aluminium, IP66

Automation > Enclosure/switchgear cabinet (empty)
Steel Floor Standing Enclosures

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Features

  • Body: One piece enclosure body. Integrated depth profiles with hole pattern, allowing mounting plate to be adjusted in depth. The frame in multiple door versions, is divided into individual modules by means of vertical dividers.
  • Rainhood: Sloped rainhood with integrated rain gutter and ventilation channels in the perimeter.
  • Double wall: Rear and lateral double walls with top and bottom ventilation openings allowing air flow.
  • Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud.
  • "Approvals: Climatic and Chemically active substances resistance according to EN61969-3 ""Mechanical structures for electronic equipment. Outdoor enclosures”."
  • Bottom plates: Supplied as accessory.
  • Rear panel: Fastened from the inside. Standard facilities for rear door mounting.
  • Protection: Complies with IP 66, TYPE 4X, 12, IK 10, when a bottom plate is fitted.
  • Material: Aluminium AlMg3. Frame: 2 mm. Door: 2 mm. Rear panel: 2 mm. Rain hood: 2 mm. Double wall: 2 mm.
  • Lock: Espagnolette 4-point locking system. Does not interfere with the enclosure inner space. Standard lift handle with security lock.
  • Finish: RAL 7035 structure powder coating 100% polyester.
  • Door: Double walled with top and bottom ventilation openings, allowing air flow. Mounted with concealed hinges, allowing left or right hand opening. Multiple door version has individual lockable doors.
  • Delivery: Frame with fitted door with swinghandle, rear panel, rain hood and double walls. Delivery also includes earthing bolts. Delivered on a pallet which is identical to the width of the enclosure to allow baying without removal. All packing material is recyclable. Mounting plate and bottom plates are not included in the standard delivery.
Atributo del producto Valor
Height (H)1200mm
Width (W)1199mm
Depth (D)600mm
Door Quantity2
MaterialAluminum
FinishPowder Coated
ColorLight Gray
Color CodeRAL 7035
Thickness (T)2mm
Weight72kg
UPC783510478117
EAN8713574188181
Standard Packaging Quantity1
Packing Quantity1

ETIM for EKOM12126 Cabinets and enclosures (EC000261)
Feature Name Feature Value
Width (EF000008) 1.20 mm
Height (EF000040) 1.20 mm
Depth (EF000049) 600.00 mm
Material (EF002169) Aluminium
Surface finishing (EF006569) Powder coated
Colour (EF000007) Grey
RAL-number (EF000116) 7.04
With mounting plate (EF000118) No
Mounting plate depth-adjustable (EF006054) Yes
Pole fastening (EF009582) No
Number of doors (EF000122) 2.00
Number of locks (EF000123) 1.00
Pitched roof (EF009278) No
EMC-version (EF001062) No
With glazed door (EF001089) No
With ventilation door (EF006279) No
With rear door (EF007381) No
Impact strength (EF004293) IK10
Degree of protection (IP) (EF005474) IP66
Degree of protection (NEMA) (EF011959) 4X
