View larger
Images are for illustrative purposes only. Please refer to data sheet for details
EF300-24R5 ELDON Filter Fan Air flow 256 m3/h EF300-24R5
EF300-24R5
30024
ELDON
1 Pcs.
Filter Fan Air flow 256 m3/h EF300-24R5
Fan with filter 223 m3/h, 24 V DC, 50/60 Hz, IP54
Filter Fan Air flow 223 m3/h, 24V DC, 50/60HZ, IP54
Automation > Ventilator (switchgear cabinet)
General Accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Features
- Description: Filter fan for forced ventilation. nVent HOFFMAN filter fans save time on installation as they are installed with a click-in system without screws. The hinged front cover can be easily opened for quick and easy filter replacement. The airflow direction and the connection position can easily be changed.
- Material: Front cover manufactured from injection-moulded thermoplastic, self-extinguishing, UL94V0.
- Temperature range: -40 °C to +55 °C.
- Protection: IP 54, TYPE 12.
- Finish: RAL 7035.
- Pack quantity: One fan with filter.
- The filter fan is reliable due to its high quality motor, as well as being easy to install
- Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the enclosure and the reliable motor ensures that there is constant ventilation
- The click-in feature reduces the customer's labour cost due to the ease of installation
- The filter fan should be installed together with at least one exhaust filter, EFA
- Bearing Type: Sleeve
| Atributo del producto | Valor |
|---|---|
| Aiflow Volume, Without Filter | 223/247m³/h |
| Airflow Volume, With Filter | 201/223m³/h |
| Airflow | 223m³/h |
| Height | 252mm |
| Width | 252mm |
| Depth | 103mm |
| Cutout Size | 223 x 223mm |
| Voltage DC | 24V |
| Protection Rating | IP54; NEMA Type 12 |
| Material | Thermoplastic |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Nominal Current | 0.5A |
| Connection Type | Spring Type |
| Noise Level | 42dB(A) |
| Weight | 1.45kg |
| UPC | 783510474782 |
| EAN | 8713574132696 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
| Feature Name | Feature Value |
|---|---|
| Number of fans (EF000928) | 1.00 |
| Operating voltage AC 50 Hz (EF008206) | 24.00 V |
| Operating voltage AC 60 Hz (EF008207) | 24.00 V |
| Operating voltage DC (EF008208) | 24.00 V |
| Voltage type (EF000187) | DC |
| Built as slide-in ventilator (EF007126) | Yes |
| Air circulator (EF007516) | No |
| Roof ventilator (EF007099) | No |
| With filter (EF006013) | Yes |
| Volume flow, freeblowing (EF007173) | 256.00 m³/h |
| Rated power (EF007051) | 12.00 W |
| EMC-version (EF001062) | No |
| Degree of protection (IP) (EF005474) | IP54 |
| Mounting method (EF000003) | Snap mounting |
| Suitable for 19 inch rack mounting (EF000337) | No |
| Colour (EF000007) | Grey |
| RAL-number (EF000116) | 7.04 |
| Width (EF000008) | 252.00 mm |
| Height (EF000040) | 252.00 mm |
| Depth (EF000049) | 103.00 mm |
