ELDON EFP200-24VACR5 EFP200-24VACR5 ELDON Filter Fan Air flow 56 m3/h EFP200-24VACR5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

EFP200-24VACR5 ELDON Filter Fan Air flow 56 m3/h EFP200-24VACR5

EFP200-24VACR5

20024

ELDON

1 Pcs.

Filter Fan Air flow 56 m3/h EFP200-24VACR5 Fan with filter 56 m3/h, 24 V DC, outdoor, IP55 Filter Fan Air flow 56 m3/h, 24V AC, Outdoor, IP55

Automation > Ventilator (switchgear cabinet)
General Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eldon filter fan, part number EFP200-24VACR5, supplies conditioned cooling air into automation enclosures while keeping out harmful environmental contaminants. Cabinet cooling units with integrated filter media ensure stable internal temperatures for sensitive electrical hardware. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Airflow Volume, With Filter metric: 40/46m³/h
  • Aiflow Volume, Without Filter: 56/64m³/h
  • Nominal Voltage: 24V
  • Height: 145mm
  • Width: 145mm
  • Depth: 69mm
  • Cutout Size: 125 x 125mm
  • Nominal Current: 0.21A
  • Protection Rating: IP55; NEMA Type 12
  • Material: Thermoplastic
  • Finish: Smooth
  • Color: Light Gray
  • Color Code: RAL 7035
  • Frequency: 50/60Hz
  • Connection Type: Spring Type
  • Noise Level: 44dB(A)

More info

▲

Features

  • Description: Filter fan for forced ventilation. nVent HOFFMAN filter fans save time on installation as they are installed with a click-in system without screws. The hinged front cover can be easily opened for quick and easy filter replacement. The airflow direction and the connection position can easily be changed. The new filter mat gives higher air flow and longer life, with a low pressure drop, because of special construction. The UV resistance of the housing makes it the best option for outdoor applications.
  • Material: Front cover manufactured from injection-moulded thermoplastic, self-extinguishing, UL94V0. UV resistance.
  • Temperature range: -40 °C to +55 °C.
  • Protection: IP 55 TYPE 12.
  • Finish: RAL 7035.
  • Pack quantity: One fan with filter.
Atributo del producto Valor
Airflow Volume, With Filter metric40/46m³/h
Aiflow Volume, Without Filter56/64m³/h
Nominal Voltage24V
Height145mm
Width145mm
Depth69mm
Cutout Size125 x 125mm
Nominal Current0.21A
Protection RatingIP55; NEMA Type 12
MaterialThermoplastic
FinishSmooth
ColorLight Gray
Color CodeRAL 7035
Frequency50/60Hz
Connection TypeSpring Type
Noise Level44dB(A)
Weight0.5kg
UPC783510476151
EAN8713574161764
Standard Packaging Quantity1
Packing Quantity1
