EFA500-700R5 ELDON Exhaust filter
EFA500-700R5
500700
ELDON
1 Pcs.
Automation > Cartridge air filter
General Accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
EFA500-700R5 ELDON Exhaust filter functions as a high-capacity outlet vent for heavy-duty industrial cabinets, allowing warm air to escape while blocking external particulates. Ventilation solutions of this type are crucial for maintaining safe operating environments for sensitive electronic equipment.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height: 320 mm
- Width: 320 mm
- Depth: 39 mm
- Product Family: Climate Control
- Material: Thermoplastic
- Finish: Smooth
- Color: Light Gray
- Color Code: RAL 7035
- Weight: 0.9 kg
- UPC: 783510475178
- EAN: 8713574132849
- Standard Packaging Quantity: 1.0000
- Packing Quantity: 1.0000
- Nominal flow rate (EF023189): None m³/h
- Width (EF000008): None mm
- Height (EF000040): None mm
More info
▲Features
- Description: Exhaust filter to be used for natural ventilation, or for forced ventilation working with filter fans EF. nVent HOFFMAN exhaust filters save us time because are installed with a click-in system without screws. The hinged front cover can be easily opened for quick and easy filter replacement.
- Material: Front cover made of injection-moulded thermoplastic, self-extinguishing, UL94V0.
- Temperature range: -40 °C to +55 °C.
- Protection: IP 54, TYPE 12.
- Finish: RAL 7035.
- Approvals: CE, EAC, cRUus_UL Recognized.
- Pack quantity: One exhaust filter.
- Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the enclosure
- The click-in feature reduces the customer's labour cost due to the ease of installation
- To guarantee natural ventilation, install at least two exhaust filters
- Forced ventilation can be achieved by adding filter fans, EF
- Filter mat (EN779): EFA100R5, EFA200R5, EFA220R5, EFA250-300R5 - G4; EFA500-700R5 - G3
- Filtration efficiency (%): >90
| Atributo del producto | Valor |
|---|---|
| Height | 320 mm |
| Width | 320 mm |
| Depth | 39 mm |
| Product Family | Climate Control |
| Material | Thermoplastic |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Weight | 0.9 kg |
| UPC | 783510475178 |
| EAN | 8713574132849 |
| Standard Packaging Quantity | 1.0000 |
| Packing Quantity | 1.0000 |
