UDP100125 ELDON ARM.POL. 1000x1250x320 2P, ARM.POL. 1000x1250x320 2P
UDP100125
100125
ELDON
1 Pcs.
Automation > Enclosure/switchgear cabinet (empty)
Polyester Uniplast enclosures
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Designed for robust environmental resistance, this Eldon UDP100125 polyester wall mounted enclosure protects sensitive electrical distribution assets. Non-metallic enclosures provide reliable shielding against moisture and chemical exposure in harsh facilities.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height (H): 1000mm
- Width (W): 1250mm
- Depth (D): 320mm
- Door Quantity: 2
- Weight: 41kg
- Material: Polyester
- Finish: Smooth
- Color: Light Gray
- Color Code: RAL 7035
- UPC: 783510530433
- EAN: 8713574100183
- Standard Packaging Quantity: 1
- Packing Quantity: 1
- Width (EF000008): 1.25 mm
- Height (EF000040): 1.00 mm
- Depth (EF000049): 320.00 mm
More info
▲Features
- Material: Fibre-glass reinforced polyester.
- Body: Modular moulded, with rear fixing. Direct fixing to the wall or by use of wall mounted brackets. To a pole by use of EPF, to the floor by use of the plinth UPP or DIN-base UAF and UMPS. In double door enclosures, sealing is ensured by a neoprene gasket.
- Door: Flush mounted door, with or without window and 100° opening. For larger sizes, a door support is supplied for easier closing.
- Lock: Premounted handle, suitable for all types of half cylinder locks (standard depth of 40 mm). Five locking points (three points in 500 mm width enclosures).
- Temperature resistance: -25 °C to 70 °C in continuous use (peak temperatures up to 130 °C).
- Characteristics: Self extinguishing and halogen free. Double insulated, according to EN61439-1. Rated insulation voltage Ui=1000V.
- Protection: Complies with IP 65 for double door enclosures. Impact resistance IK 10.
- Approvals: CE, GOST. For further approvals, please contact nVent HOFFMAN's sales department.
- Finish: RAL 7035, precoloured raw material.
- Delivery: Enclosure with door, fixing screws for the mounting plate and wall mounting brackets. (Lock cylinder is not included in the delivery).
| Atributo del producto | Valor |
|---|---|
| Height (H) | 1000mm |
| Width (W) | 1250mm |
| Depth (D) | 320mm |
| Door Quantity | 2 |
| Weight | 41kg |
| Material | Polyester |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| UPC | 783510530433 |
| EAN | 8713574100183 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
