View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MSMCP3006-2R5 ELDON Modular front panel, 300x600 MSMCP3006-2R5
MSMCP3006-2R5
30062
ELDON
1 Pcs.
Modular front panel, 300x600 MSMCP3006-2R5
Front Panel modular, 300x600, 2 DIN rail, 50 modules
Modular front panel, 300x600, 2 DIN rails
Automation > Front plate (switchgear cabinet)
Power and distribution
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Features
- Description: Slotted front panel for modular assemblies. Provided with one DIN rail per row for modular components. It has a top and bottom bending to provide extra rigidity.
- Material: 1.25 mm steel.
- Finish: RAL 7035 structured powder coating.
- Delivery: 1 piece with mounting material.
- Mounting requirements: To be assembled on the modular system frame.
- The panels are to be mounted onto a fix system front frame (MSFCP) or onto modular system frames (MSMSF or MSMSM)
- Slotted front panel for modular assemblies
- Provided with one DIN rail per row for modular components
- It has a top and bottom bending to provide extra rigidity
- One piece with mounting material
- To be assembled on the modular system frame
| Atributo del producto | Valor |
|---|---|
| Height | 300mm |
| Width | 600mm |
| Depth | 13mm |
| Enclosure Material | Mild Steel |
| Product Family | Free-Standing; Wall Mounted |
| Material | Mild Steel |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thickness | 1.25mm |
| Panel Quantity | 2 |
| DIN Rail | 50 |
| UPC | 783510518387 |
| EAN | 8713574131309 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
| Feature Name | Feature Value |
|---|---|
| Width (EF000008) | 600.00 mm |
| Height (EF000040) | 300.00 mm |
