MKSL20104R5 ELDON Self-supporting, 2000x1000x400, compact, no door, no MP, mild steel
MKSL20104R5
20104
ELDON
1 Pcs.
Automation > Enclosure/switchgear cabinet (empty)
Power and distribution
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Self-supporting, 2000x1000x400, compact, no door, no MP, mild steel manufactured by Eldon under part number MKSL20104R5 provides a rack-style modular framework for organizing electrical control equipment, telecommunications hardware, and instrumentation gear. These open-access structures facilitate efficient cable management and component mounting in industrial control rooms.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height: 2000mm
- Width: 1000mm
- Depth: 400mm
- Rack Units: 36U
- Material: Steel
- Finish: Powder Coated
- Color: Light Gray
- Color Code: RAL 7035
- Thickness: 1.35mm
- UPC: 783510506575
- EAN: 8713574128101
- Standard Packaging Quantity: 1
- Packing Quantity: 1
More info
▲Features
- Material: Body: 1.35 mm painted steel. Rear and roof panels: 1.5 mm painted steel.
- Body: Four times folded and seam-welded frame. Integrated double row hole pattern.
- Rear panel: Fitted by M6 torxscrews. Standard facilities for rear door mounting.
- Roof panel: Removable.
- Earthing: All panels are earthed through their fittings and are equipped with a separate earthingstud.
- Finish: RAL 7035 structured powder coating.
- Protection: IP 44, 55 TYPE 12 IK 10, depending of the doors configuration.
- Delivery: Body with rear panel and roof panel. Delivery also includes earthing bolts. Delivered on a pallet with identical width of the enclosure. All packing material is recyclabl
| Atributo del producto | Valor |
|---|---|
| Height | 2000mm |
| Width | 1000mm |
| Depth | 400mm |
| Rack Units | 36U |
| Material | Steel |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thickness | 1.35mm |
| UPC | 783510506575 |
| EAN | 8713574128101 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
