ELDON DPCP162412TE DPCP162412TE ELDON Terminal box, 160x240x121 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

DPCP162412TE ELDON Terminal box, 160x240x121

DPCP162412TE

162412

ELDON

1 Pcs.

Terminal box, 160x240x121 Box for terminals, 160x240x121, transparent cover, without MP, polycarbonate, IP66 Small Polycarbonate Terminal Box, DPCP, 160x240x121, Light Gray, Polycarbonate

Automation > Empty cabinet
Terminal Boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Safeguarding electrical junction points and control wiring against harsh conditions is the standard use case for this Eldon polycarbonate terminal box. These rugged enclosures provide dependable protection for industrial automation setups.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height: 160 mm
  • Width: 240 mm
  • Depth: 121 mm
  • Max Mounting Depth: 107.5 mm
  • Material: Polycarbonate
  • Finish: Smooth
  • Color: Light Gray
  • Color Code: RAL 7035
  • EAN: 6418677177293
  • Standard Packaging Quantity: 1.0000
  • Packing Quantity: 1.0000

More info

▲

Features

  • Description: Polycarbonate box, halogen-free, suitable for outdoor use. High UV radiation resistance. Self-extinguishing.
  • Material: Polycarbonate.
  • Gasket: Polyurethane gasket integrated in the box cover.
  • Temperature resistance: -40 °C to +80 °C.
  • Flammability: UL746C 5V.
  • Protection: IP 66, 67 IK 08 (-25 °C … +35 °C).
  • Finish: RAL 7035.
  • Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide.
  • Flammability: UL746C 5V
  • Protection: IP 66, 67 IK 08 (-25 °C … +35 °C)
  • Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide
Atributo del producto Valor
Height160 mm
Width240 mm
Depth121 mm
Max Mounting Depth107.5 mm
MaterialPolycarbonate
FinishSmooth
ColorLight Gray
Color CodeRAL 7035
EAN6418677177293
Standard Packaging Quantity1.0000
Packing Quantity1.0000

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
