DPCP162409TE ELDON Terminal box, 160x240x91
DPCP162409TE
162409
ELDON
1 Pcs.
Automation > Empty cabinet
Terminal Boxes
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Eldon DPCP162409TE terminal box provides reliable mechanical protection and environmental shielding for electrical terminal strips, wiring networks, and compact control devices. Polycarbonate junction enclosures are standard across automation installations requiring high impact tolerance.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- Height: 160 mm
- Width: 240 mm
- Depth: 91 mm
- Max Mounting Depth: 77.5 mm
- Material: Polycarbonate
- Finish: Smooth
- Color: Light Gray
- Color Code: RAL 7035
- EAN: 8713574087880
- Standard Packaging Quantity: 1.0000
- Packing Quantity: 1.0000
More info
▲Features
- Description: Polycarbonate box, halogen-free, suitable for outdoor use. High UV radiation resistance. Self-extinguishing.
- Material: Polycarbonate.
- Gasket: Polyurethane gasket integrated in the box cover.
- Temperature resistance: -40 °C to +80 °C.
- Flammability: UL746C 5V.
- Protection: IP 66, 67 IK 08 (-25 °C … +35 °C).
- Finish: RAL 7035.
- Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
- Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide.
- Flammability: UL746C 5V
- Protection: IP 66, 67 IK 08 (-25 °C … +35 °C)
- Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide
| Atributo del producto | Valor |
|---|---|
| Height | 160 mm |
| Width | 240 mm |
| Depth | 91 mm |
| Max Mounting Depth | 77.5 mm |
| Material | Polycarbonate |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| EAN | 8713574087880 |
| Standard Packaging Quantity | 1.0000 |
| Packing Quantity | 1.0000 |
