View larger
Images are for illustrative purposes only. Please refer to data sheet for details
DPCP152008TE ELDON Terminal box, 150x200x76
DPCP152008TE
152008
ELDON
1 Pcs.
Terminal box, 150x200x76
Box for terminals, 150x200x76, transparent cover, without MP, polycarbonate, IP66
Small Polycarbonate Terminal Box, DPCP, 150x200x76, Light Gray, Polycarbonate
Automation > Empty cabinet
Terminal Boxes
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Features
- Description: Polycarbonate box, halogen-free, suitable for outdoor use. High UV radiation resistance. Self-extinguishing.
- Material: Polycarbonate.
- Gasket: Polyurethane gasket integrated in the box cover.
- Temperature resistance: -40 °C to +80 °C.
- Flammability: UL746C 5V.
- Protection: IP 66, 67 IK 08 (-25 °C … +35 °C).
- Finish: RAL 7035.
- Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
- Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide.
- Flammability: UL746C 5V
- Protection: IP 66, 67 IK 08 (-25 °C … +35 °C)
- Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide
| Atributo del producto | Valor |
|---|---|
| Height (H) | 150mm |
| Width (W) | 200mm |
| Depth (D) | 76mm |
| Max Mounting Depth | 62mm |
| Weight | 0.42kg |
| Material | Polycarbonate |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| EAN | 8713574087866 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
