DPCP121209TE ELDON Terminal box, 120x122x86
DPCP121209TE
121209
ELDON
1 Pcs.
Automation > Empty cabinet
Terminal Boxes
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eldon terminal box, part number DPCP121209TE, is engineered to protect electrical terminations, splices, and small control components from adverse environmental factors. Polycarbonate junction boxes are frequently used in commercial and light industrial installations to ensure dependable circuit protection.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height: 120 mm
- Width: 122 mm
- Depth: 86 mm
- Max Mounting Depth: 72 mm
- Material: Polycarbonate
- Finish: Smooth
- Color: Light Gray
- Color Code: RAL 7035
- EAN: 6418677177231
- Standard Packaging Quantity: 1.0000
- Packing Quantity: 1.0000
More info
▲Features
- Description: Polycarbonate box, halogen-free, suitable for outdoor use. High UV radiation resistance. Self-extinguishing.
- Material: Polycarbonate.
- Gasket: Polyurethane gasket integrated in the box cover.
- Temperature resistance: -40 °C to +80 °C.
- Flammability: UL746C 5V.
- Protection: IP 66, 67 IK 08 (-25 °C … +35 °C).
- Finish: RAL 7035.
- Approvals: CE, GOST. For cULus_UL Listed approvals, please contact our sales department.
- Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide.
- Flammability: UL746C 5V
- Protection: IP 66, 67 IK 08 (-25 °C … +35 °C)
- Delivery: Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made of polyamide
| Atributo del producto | Valor |
|---|---|
| Height | 120 mm |
| Width | 122 mm |
| Depth | 86 mm |
| Max Mounting Depth | 72 mm |
| Material | Polycarbonate |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| EAN | 6418677177231 |
| Standard Packaging Quantity | 1.0000 |
| Packing Quantity | 1.0000 |
